Graco RAC X Spray Tips: Complete Size Guide & Selection
July 02, 2026 • 7 min read
Quick Answer
Graco RAC X tip numbers encode both the fan width and the orifice size. Multiply the first digit(s) by 2 for fan width in inches. The last two digits are the orifice size in thousandths of an inch. A 515 tip = 10-inch fan, 0.015" orifice. For standard latex on walls use a 515 or 517. For fine finishes use a 208 or 310. For decks and fences use a 415 or 515. For thick coatings use a 619 or 621.
Every Graco tip number contains two pieces of information — the spray fan width and the orifice size. Once you understand this system, choosing the right tip becomes straightforward.
515
First Digit(s)
Fan Width ÷ 2
5 × 2 = 10" fan
Last Two Digits
Orifice Size
0.015" opening
So a 515 tip produces a 10-inch wide fan (5 × 2) through a 0.015-inch orifice. A 619 produces a 12-inch fan through a 0.019-inch orifice. Simple once you know the formula.
General rule: Larger orifice = more material output = better for thick coatings. Wider fan = faster coverage = better for large flat surfaces. Narrower fan + small orifice = finer atomisation = better for detailed or fine finish work.
2. Full RAC X Size Chart
Tip Size
Fan Width
Orifice
Best For
Typical Material
208
4"
0.008"
Fine detail, trim, cabinets
Lacquer, stain, varnish
210
4"
0.010"
Trim, doors, fine finish
Enamels, light latex
310
6"
0.010"
Cabinets, furniture
Lacquer, enamel
312
6"
0.012"
Trim, doors, moderate detail
Latex, enamel
412
8"
0.012"
Walls, ceilings (light latex)
Latex paint
415
8"
0.015"
Walls, fences, decksPopular
Latex, deck stain
515
10"
0.015"
Walls & ceilings (standard)Most Popular
Standard latex
517
10"
0.017"
Walls & ceilings (thick latex)
Thick latex, primer
519
10"
0.019"
Heavy coatings, primers
Masonry primer, thick coatings
521
10"
0.021"
Elastomeric, block filler
Elastomeric coatings
619
12"
0.019"
Large walls, exterior
Latex, primers
621
12"
0.021"
High-volume exterior
Elastomeric, heavy latex
625
12"
0.025"
Block filler, industrial
Block filler, textured coatings
3. Best RAC X Tip for Every Job
Interior Walls & Ceilings
515 or 517
515 for standard latex; 517 if the paint is thicker or you're spraying primer. 10-inch fan gives good coverage without overspray on trim.
Doors, Trim & Cabinets
210 or 310
Narrow fan and small orifice gives fine atomisation for detail work. Reduces overspray and gives a smoother film on flat panels.
Exterior Walls (House Siding)
517 or 619
517 for smooth siding with standard latex. Step up to 619 for faster coverage on large exteriors or with thicker coatings.
Decks & Fences
415 or 515
415 for tight fence pickets and detail areas. 515 for open deck boards. Both handle deck stains and sealers well at typical viscosities.
Masonry & Block
619 or 625
Large orifice is required to push block filler or elastomeric coatings through. 625 for very heavy materials. Expect high pressure requirements.
Fine Finish / Furniture
208 or 210
Smallest orifice sizes for lacquers, varnishes, and fine enamels. Critical for smooth, dust-free finish on furniture, cabinetry, and millwork.
Thick Primers & Coatings
519 or 521
Heavier orifice needed for high-build primers, commercial coatings, and elastomerics that would clog a smaller tip within minutes.
Stains & Thin Coatings
311 or 411
Thin material runs through a small orifice easily. Using too large an orifice with stain causes runs, drips, and excess material waste.
4. How to Tell When a Tip Is Worn
Worn tips cost you more in paint, time, and finish quality. Know the signs:
Tip Wear Indicators
Good — Replace At Correct Interval
Even fan pattern from edge to edge. Consistent oval spray shape. Pressure at normal dial setting for the material. Orifice appears round when you look straight through it.
Warning — Replace Soon
Tails developing at edges of spray pattern (heavy on each side, thin in the middle). Need to increase pressure to maintain output. Orifice begins to look slightly oval.
Worn Out — Replace Now
Clearly oval or teardrop-shaped orifice. Significant tailing on spray pattern. Using noticeably more paint than usual for same coverage. Pressure dial cranked to maximum for what should be a lighter material.
Rule of thumb: A tip is ready to replace when the orifice has worn approximately 25% larger than its original size. A 0.015" tip worn to 0.019" is effectively a 019 tip — the fan narrows and output spikes. You'll use up to 40% more paint before noticing and wonder why your job cost more than expected.
5. What Does RAC X Mean?
RAC stands for Reverse-A-Clean — the key feature that makes Graco tips the industry standard for professionals. When the tip clogs, you simply:
Rotate the RAC X tip guard 180 degrees
Trigger the gun briefly — the reversed tip shoots the clog backwards out of the orifice
Rotate back to spray position and continue
The X designates the current generation, which features a harder carbide insert for longer orifice life compared to the older RAC 5 series. The RAC X guard is also compatible with older RAC 5 tips.
Shop Graco RAC X Spray Tips
All sizes in stock. Ships same day. Not sure which size? Call 713-931-4102 — free selection help.
The tip number has two parts. The first digit(s) represent the fan width — multiply by 2 to get the actual spray width in inches. The last two digits are the orifice size in thousandths of an inch. A 515 tip = 10-inch fan (5×2), 0.015-inch orifice. A 619 = 12-inch fan, 0.019-inch orifice.
For most interior wall and ceiling work with standard latex paint, a 515 is the professional standard. If you're using a thicker latex or a high-build primer, step up to a 517. For very large open exteriors where speed matters more than fine control, a 619 covers faster.
RAC stands for Reverse-A-Clean — the tip guard rotates 180° to reverse the tip orifice, allowing you to clear a clog by triggering the gun briefly without stopping work. The X designates the current generation with a harder carbide insert for longer life vs the older RAC 5.
Tip life depends on the material sprayed and how often it's used. On latex paint, a RAC X tip typically lasts 40–100 gallons before the orifice wears noticeably. Abrasive materials like textured coatings, block filler, or masonry paint wear tips much faster — sometimes in 10–15 gallons. Replace when the orifice becomes oval-shaped or tailing develops.
RAC X tips fit any airless spray gun with a standard 7/8-inch tip nut — which covers most Graco, Titan, and Wagner guns. The RAC X tip guard is also backward-compatible with Graco RAC 5 tips, though RAC 5 tip guards will not accept RAC X tips.
Pro tip: A worn spray tip looks exactly like a pressure problem. Before you tear into your pump, flip the tip 180° and test spray. If the pattern improves, it's the tip — not the pump.
