90° hydraulic elbow fitting designed to redirect fluid flow and connect JIC06 to 1/4" NPT lines in Graco high-pressure spray and fluid systems.
| Equipment / System Type | Application Area | Role of 080071 Fitting |
|---|---|---|
| Graco hydraulic spray systems | Industrial coatings and material transfer | Provides 90° directional flow connection between JIC and NPT lines |
| Graco fluid handling equipment | High-pressure pumping systems | Enables compact hose routing and directional line adjustment |
| Graco pump assemblies | Sealants, adhesives, and coatings | Helps connect mixed-thread hydraulic or fluid lines securely |
| Graco industrial spray equipment | Manufacturing and finishing applications | Improves hose alignment in tight installation spaces |
The Graco 080071 Elbow Fitting is an OEM 90-degree hydraulic connector designed to join JIC06 and 1/4" NPT male/female threaded lines in Graco fluid handling systems. It is used to redirect fluid flow while maintaining a secure, leak-resistant connection under pressure.
Its angled design helps optimize hose routing in confined spaces, reducing strain on lines and improving overall system layout in high-pressure spray and fluid transfer applications.
The 080071 elbow fitting is commonly used in Graco spray equipment, hydraulic assemblies, and industrial fluid systems where space-saving hose routing and reliable directional flow are required. It supports efficient system configuration in tight or complex installations.
