Graco 16N496 Kit, Piston Rod, Repair

Graco 16N496 Kit Piston Rod Repair — OEM replacement rod assembly to restore pump performance and pressure consistency.

Brand: Graco
Type: Piston Rod Repair Kit
Application: Airless sprayer pump fluid section repair
Fit/Ports: Specific pump assemblies (check OEM fitment)
Material: Chromex treated hardened steel rod

Based on 0 reviews

Description

Compatible Machines / Systems

Graco airless sprayers requiring piston rod replacement
TexSpray Mark X, 7900 HD, GMAX II series (verify exact fit)
OEM pump fluid sections where 16N496 is specified

Product Overview

Manufacturer	Graco
Model Number	16N496
Type	Piston Rod Repair Kit
Center Section Material	Chromex-treated Steel
Port Size	OEM Pump Specific
Air Inlet	N/A
Wetted Material	Hardened Steel
Compatible Media	Paints, Coatings, Texture Materials

Frequently Asked Questions

The kit includes the OEM piston rod assembly engineered to restore consistent pump stroke performance. It may not include seals or packings unless specified.

Replace when there’s visible wear, scoring, or if pressure consistency drops during spraying operations. OEM replacements extend pump life. :contentReference[oaicite:1]{index=1}

Basic mechanical skills are required. Always depressurize and follow the service manual to safely disassemble the fluid section and install the rod. :contentReference[oaicite:2]{index=2}
