Graco 24H648 Box, Die, Weldment, 4"-4"-4"
OEM weldment box assembly designed to maintain accurate die alignment for 4"-4"-4" double-line thermoplastic pavement marking applications.
- 4"-4"-4" double-line die box configuration
- Compatible with select Graco ThermoLazer® systems
- Supports SmartDie™ II and FlexDie™ assemblies
- Heavy-duty welded construction for long service life
- Helps ensure consistent line width and spacing
Precision Weldment Component for Double-Line Thermoplastic Die Assemblies
Compatible Machines
| Machine | Compatibility |
|---|---|
| Graco ThermoLazer® 200 | Compatible with the 24H436 double-line die box assembly featuring the 4"-4"-4" configuration. |
| Graco ThermoLazer® 200TC | Used as the OEM weldment box component within the SmartDie™ II/FlexDie™ double-line screed box assembly. |
| Graco ThermoLazer® 300TC | Fits compatible 4"-4"-4" double-line die box systems used for thermoplastic pavement marking. |
| SmartDie™ II / FlexDie™ Systems | Designed specifically for the 4"-4"-4" double-line die box assembly (Part 24H436). |
Purpose of the Weldment Box Assembly
The Graco 24H648 Box, Die, Weldment, 4"-4"-4" is a genuine OEM structural weldment used in Graco double-line thermoplastic die box assemblies. It forms the primary housing that supports and aligns the internal die components, helping produce two uniform 4-inch pavement marking lines with a 4-inch gap.
Manufactured for demanding road-marking applications, this precision weldment maintains proper die alignment, withstands continuous exposure to heated thermoplastic materials, and helps deliver consistent striping performance in professional pavement marking equipment.
Key Benefits
- OEM weldment for 4"-4"-4" double-line die box assemblies
- Maintains accurate die positioning for uniform line widths
- Heavy-duty construction for demanding thermoplastic striping applications
- Supports long-term durability and reliable pavement marking performance
- Engineered for precise fit within compatible Graco die systems
