Graco 24H702 Kit, 3:1 Tote Mount Top-Npt
Top-mounted 3:1 pneumatic pump system designed for direct lubricant transfer from industrial IBC totes, delivering consistent oil flow for maintenance and service operations.
- 3:1 air-operated piston pump for controlled oil dispensing
- Top-mount configuration for direct tote installation
- NPT threaded connections for standard fluid integration
- Compatible with industrial IBC tote lubrication systems
Top-Mounted Tote Lubrication Pump System for Direct Industrial Oil Transfer
Compatible Machines
| Equipment Type | Compatibility Details |
|---|---|
| Graco LD Series Lubrication Systems | Works with LD Series 3:1 pump assemblies designed for top-mount installation on industrial IBC tote containers. |
| IBC Tote Oil Dispensing Units | Engineered for direct mounting on standard industrial tote lids for lubricant extraction and transfer. |
| Centralized Lubrication Networks | Integrates into facility-wide lubrication systems using NPT-threaded fluid connections. |
| Industrial Maintenance Service Systems | Suitable for workshop and field service lubrication setups requiring portable tote-mounted pumping solutions. |
Product Overview
The Graco 24H702 Kit, 3:1 Tote Mount Top-NPT is a pneumatic lubrication pump system designed for direct mounting on the top of industrial IBC totes. It enables efficient transfer of lubricants using a 3:1 air-operated piston pump for consistent and controlled oil delivery.
Configured with NPT threaded connections, it ensures compatibility with standard North American piping systems and fluid distribution setups. The top-mount design allows direct extraction from tote containers, reducing installation complexity and improving space efficiency in lubrication stations.
Built for industrial durability, the system features a modular air motor design and wear-resistant sealing components that support long service life and reduced maintenance in demanding environments.
Key Features
- 3:1 air-operated piston pump for controlled oil dispensing
- Top-mount design for direct installation on IBC tote lids
- NPT threaded connections for standard fluid integration
- Designed for industrial lubricant transfer systems
- Compatible with LD Series lubrication platforms
