XD Series 80 Heavy-Duty Low-Pressure Hose Reel System
Compatible Machines
- Mobile lubrication service trucks using XD Series fluid dispensing systems
- Fleet maintenance units equipped with onboard oil and grease delivery setups
- Industrial workshops operating low-pressure lubrication and transfer systems
- Fixed service bays requiring high-capacity hose management reels
- Bulk fluid handling installations using 1/2 in. NPT XD Series reel connections
Product Overview
Graco 24T132 Xd Series 80 Reel, 8020, Lp, Bare, Npt, Yellow replaces Graco 24R568 and multiple other... is a high-capacity hose reel designed for low-pressure lubrication and fluid transfer applications in heavy-duty service environments.
Built on the XD Series 80 platform, it delivers reliable hose control, durability, and smooth operation for continuous-use industrial and mobile fluid systems.
Key Features
- XD Series 80 (8020) heavy-duty reel engineered for maximum hose capacity
- Low-pressure (LP) lubrication and fluid transfer compatibility
- Bare configuration for flexible integration into custom systems
- 1/2 in. NPT inlet connection for standard industrial setups
- Replaces Graco 24R568 and multiple legacy reel models
Installation & Application Benefits
- Improves hose management efficiency in high-volume service operations
- Reduces hose wear through controlled retraction and guided payout
- Enhances safety and cleanliness in industrial fluid handling environments
- Supports flexible installation in mobile and fixed service setups
- Maintains consistent performance under continuous industrial workloads
Frequently Asked Questions
It is used for controlled hose management in high-capacity low-pressure lubrication and fluid transfer systems across industrial and mobile service environments.
It is compatible with XD Series lubrication systems, fleet service trucks, workshop fluid dispensing setups, and bulk fluid handling installations.
The 8020 designation refers to the XD Series 80 platform configuration optimized for the highest capacity hose handling in this series.
It uses a 1/2 inch NPT inlet connection compatible with standard industrial lubrication and fluid transfer systems.
