Graco 223674 Pump Repair kit

The Graco 223674 Pump Repair Kit restores worn internal parts in Monark and EH-series pumps, improving sealing and extending service life.

  • Genuine Graco replacement kit
  • Includes UHMWPE & leather packings
  • Fits Monark 23:1, EH333, and EH300 (SD) pumps
  • Ideal for restoring pressure and performance

Retail Price: $147.5
You save: $41.22 (27.95%)
Our Price: $106.28
0
Based on 0 reviews
5
0%
4
0%
3
0%
2
0%
1
0%

Fitment & Key Details for Maintenance Pros

Compatible Machines

This genuine Graco kit services specific high-ratio displacement pumps. Always confirm against your pump’s parts list.

  • Graco Monark 23:1 Pump
  • Graco EH333 Pump
  • Graco EH300 (SD) Pump

What is the Graco 223674 Pump Repair Kit?

The Graco 223674 Pump Repair Kit is a genuine service kit for renewing internal wear components—packings, seals, and related parts—inside compatible Graco displacement pumps. It restores sealing efficiency, reduces by-pass, and extends pump life without replacing the entire pump assembly.

This kit is commonly described as a UHMWPE/Leather packing conversion set, balancing chemical resistance and long wear for demanding daily use.

Quick Specs

Part / SKU 223674
Kit Type Pump Repair / Packing Kit (internal service parts; not a full pump)
Typical Materials UHMWPE & Leather packings (durable wear & fluid compatibility)
Applications General coatings & industrial fluids compatible with the above packing set
Fits See Compatible Machines list above

What’s Typically Included

  • Upper & lower packings and sealing elements
  • Associated gaskets / wear rings as specified for the pump
  • Service items needed to correctly re-seal the displacement rod & housing

When to Choose This Kit

  • Loss of pressure, by-pass, or visible leakage from the pump
  • Poor priming or pulsation that points to worn packings
  • Routine preventive maintenance at manufacturer-recommended intervals

Install Notes (Summary)

  1. Depressurize, flush, and safely disassemble per manual.
  2. Inspect rod, seat, and housing for scoring; replace damaged hardware.
  3. Lubricate new packings as specified; observe correct stack orientation.
  4. Reassemble to torque; pressure-test with compatible fluid and check for leaks.

Frequently Asked Questions

No. It’s a repair/packing kit for internal wear components. The pump body and major hardware are reused if in good condition.

Match your exact pump model (e.g., Monark 23:1, EH333, EH300 (SD)) against your parts list. Only use this kit where 223674 is specified by Graco.

The combination balances wear resistance and fluid compatibility, providing durable sealing performance across common industrial coatings.

Yes—check the displacement rod for scoring, seats for pitting, and bearings/bushings for excessive play. Replace any damaged parts to avoid premature failure of new packings.

No. A repair kit restores sealing; it does not alter the pump’s mechanical ratio or displacement. Performance should return to spec if all components are within tolerance.
