Graco 110816 Clip Spring

The Graco 110816 Clip Spring is a genuine OEM part used to secure motor brushes in Graco airless sprayers, ensuring stable contact and reliable motor operation.

  • Part Number: 110816
  • Component Type: Motor Brush Clip Spring
  • Compatible Models: Graco Ultra 795, 1095, and similar
  • Used With: Motor Brush Kits 220853 & 222157
  • Function: Holds brushes securely for consistent electrical contact

$9.25
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Comprehensive Overview of Graco 110816 Clip Spring

Compatible Machines

  • Graco Ultra 795 Airless Sprayer
  • Graco Ultra 1095 Airless Sprayer
  • Machines using motor brush kits 220853 (110–120 V) and 222157 (220–240 V)
  • Various Graco electric airless sprayers with compatible brush assemblies

Product Description

The Graco 110816 Clip Spring is a genuine OEM component designed to securely hold motor brush assemblies in place within Graco airless sprayer motors. Its precise tension ensures proper brush alignment and consistent electrical contact, maintaining motor performance and reliability under demanding operation.

Key Features

  • Manufactured from durable, spring-tempered steel
  • Ensures reliable tension for motor brush retention
  • Maintains consistent electrical contact for efficient motor function
  • OEM-quality part providing precise fitment and long service life
  • Easy to install during routine motor brush replacement

Technical Specifications

Specification Details
Part Number 110816
Component Type Clip Spring
Material Spring Steel
Primary Function Secures motor brushes in holder assembly
Compatible Motor Kits 220853 (110–120 V), 222157 (220–240 V)
OEM Manufacturer Graco Inc.

Usage and Maintenance

When replacing the motor brushes, the Clip Spring should be inspected for wear or deformation. If weakened or bent, replacement is recommended to ensure secure brush placement. Always disconnect power and depressurize the sprayer before performing any maintenance on electrical components.

Benefits

  • Ensures stable and reliable motor brush positioning
  • Reduces sparking and electrical arcing
  • Supports consistent motor operation and extended service life
  • Designed for precise fitment on OEM Graco assemblies

Frequently Asked Questions

The Graco 110816 Clip Spring is used to secure the motor brushes in place, maintaining proper tension and electrical contact within the motor assembly of compatible Graco sprayers.

This part is compatible with Graco Ultra 795 and Graco Ultra 1095 sprayers, as well as machines using motor brush kits 220853 and 222157.

Replace the Clip Spring whenever the motor brushes are replaced or if the clip shows signs of wear, bending, or reduced tension to ensure optimal motor performance and safety.
