Graco 288233 Frame Cart Lo Aa

The Graco 288233 Frame, Cart, LO, AA is a genuine replacement low-boy cart frame designed to restore stability and mobility to compatible Graco airless sprayers.

  • OEM structural cart and chassis assembly
  • Low-boy (LO) frame design for balanced support
  • Used on select Graco cart-mounted airless sprayer models

List Price: $462
You save: $67.45 (14.60%)
Sale Price: $394.55
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Compatible Machines & Part Overview

The Graco 288233 Frame, Cart, LO, AA is a genuine OEM cart/frame assembly designed to support and mobilize select Graco airless sprayers that are built on a low-boy style cart base. It provides a stable structure for mounting the pump, motor or engine, controls, and wheels for jobsite portability.

Compatible Machine Families

  • Graco Gas Airless Sprayer Series that originally mount on low-boy frames
  • Graco Hydraulic/Cart-mounted Airless Sprayer Units with LO/AA chassis
  • Heavy-duty Contractor-grade Cart Sprayers configured with AA accessories
  • Legacy Graco Sprayers originally shipped on a similar low-boy cart

Key Features

Part Number 288233
Product Type Cart/Frame Assembly
Frame Style Low-boy (LO), with AA accessory configuration
Intended Use Replacement OEM cart for select Graco sprayers
Material Durable metal frame with mounting points for wheels/axle and sprayer assembly

Product Description

This OEM Graco cart/frame is designed as the structural base for certain Graco airless sprayers configured with a low-boy cart. It supports the main sprayer components such as pump, engine/motor, controls, and wheels to enable mobility and stable operation on job sites. Typical uses include finishing, painting, and industrial coating applications where a robust cart frame is needed.

Frequently Asked Questions

The 288233 cart/frame replaces the original low-boy chassis on compatible Graco airless sprayers that were originally supplied with an LO/AA style frame. It restores mobility and structural support when the original frame is damaged or worn.

To confirm compatibility, check your sprayer’s model and serial number against the OEM parts diagram for that machine. If the original frame part number matches 288233 or is listed as a compatible replacement, this is the correct frame assembly.

The cart/frame assembly typically includes mounting points for the axle and wheels, but the wheels and axle may be sold separately depending on the supplier. Confirm the included components when ordering.
