Graco 243177 Pump Cylinder Repair Kit
$174.91
$237.00
Save 26%
Available to Order
Graco 243177 Pump Cylinder Repair Kit is a genuine OEM replacement kit designed for restoring pump performance on older Ultra Max 695 sprayers. Perfect for fixing pressure loss or worn cylinder issues.
- Fits Ultra Max 695 (1st & 2nd Series, pre-2000)
- Includes pump cylinder/sleeve and sealing components
- Improves pressure consistency and spray performance
- Durable OEM construction for long-term reliability
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Compatibility & Key Details
Compatible Machines
Use the model/series plate on your sprayer to confirm exact series and build year.
- Graco Ultra Max 695 — 1st Series
- Graco Ultra Max 695 — 2nd Series
- Graco Ultra Max 695 (pre-2000)
Product Overview
The Graco 243177 Pump Cylinder Repair Kit restores proper sealing and pumping performance in the cylinder section of older Ultra Max 695 pumps. It’s a genuine OEM kit designed to address wear in the sleeve/cylinder area so your sprayer can build and maintain pressure reliably.
Key Features
- OEM reliability – correct materials, dimensions, and tolerances for Ultra Max 695 (older series).
- Pressure recovery – resolves loss of output due to worn cylinder/sleeve seals.
- Service-friendly – kit format simplifies a targeted repair without replacing the entire pump.
Specs & Fit Notes
| Part Number | 243177 |
|---|---|
| Item Type | Pump Cylinder Repair Kit (cylinder/sleeve & related sealing components) |
| Intended Models | Ultra Max 695 (1st & 2nd Series; pre-2000) |
| Typical Symptoms Addressed | Low pressure, weak spray pattern, internal bypass/leakage, visible cylinder wear |
| Installation Note | Clean bore, inspect rod/packings; lubricate seals; torque to spec per model manual |
What’s Included*
- Pump cylinder/sleeve (model-specific)
- Associated seals/O-rings and hardware for cylinder section
Helpful Tips
- Verify your sprayer’s series (1st/2nd) and build year before ordering.
- Inspect the piston rod and packings; replace if scored or excessively worn.
- Flush and filter fluid before first run after repair to protect the rebuilt cylinder.
Frequently Asked Questions
No—this kit is intended for older Ultra Max 695 (1st & 2nd Series; pre-2000). Ultra Max II and later revisions typically use different pump components. Check your exact model/series and consult the parts manual for the correct cylinder kit.
Persistent loss of pressure, weak or pulsing spray, internal bypass (unit runs but won’t build pressure), or visible scoring in the cylinder bore are common signs the pump cylinder is worn and the Graco 243177 Pump Cylinder Repair Kit may be needed.
Basic hand tools typically suffice. Follow the service manual for torque specs and assembly order. A clean bench, proper seal lubricant, and a torque wrench help ensure a reliable repair.
It’s a good idea to inspect packings and the piston rod while the pump is apart. If there is scoring or excessive wear, replace those components now to avoid a second teardown soon after the cylinder repair.
Match your sprayer’s exact model ID, series (1st/2nd), and build year with the parts breakdown. If your unit is Ultra Max 695 (pre-2000), this kit is the specified cylinder repair. When in doubt, contact support with your serial number.
