Graco 113094 Internal Retaining Ring

Graco 113094 Internal Retaining Ring Overview

The Graco 113094 Internal Retaining Ring is a critical OEM part used to secure internal components within Graco housings and pinion assemblies, ensuring reliable performance under mechanical loads.

Compatible Machines

• Graco GMax 3900 – Pinion housing assembly
• Graco GMax 5900 / 5900HD – Drive / pinion housing
• LineLazer III 3900 – Pinion housing / drive-housing parts

Key Features

• OEM-quality internal retaining ring designed for durability
• Secures shafts and bearings in Graco housings
• Ensures proper alignment and tension within assemblies
• Easy installation and removal with proper snap-ring pliers

Maintenance Tips

• Inspect for wear or deformation before reinstalling
• Replace if fatigued or damaged to prevent mechanical failure
• Use appropriate tools to avoid damaging the ring or groove
