Graco 114110 Fitting Elbow Male Swivel
$28.20
Available to Order
The Graco 114110 is a 90° male swivel elbow designed for ½″ OD tubing and ½″ NPT connections, ideal for high-pressure routing in Graco proportioners and plural-component systems.
- Connection: ½″ NPT (male) × ½″ OD tube
- Swivel Design: 360° rotation for flexible alignment
- Application: Plural-component sprayers, proportioners, manifolds
- Durable: Corrosion-resistant metal construction
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Graco 114110 Male Swivel Elbow Fitting – Technical Overview
The Graco 114110 is a 90° elbow fitting with a male swivel designed for use with ½″ OD tubing and ½″ NPT (male) connections. It provides flexible routing, reduces stress on tubing, and is ideal for high-pressure proportioning systems.
Compatible Machines
- Graco SuperCat Proportioner Packages
- Graco Wall-Mounted Air-Assisted or Airless Packages
- Pneumatic Crossover Kits
- Graco Xtreme Mix / Plural-Component Proportioners (e.g., Xtreme Mix 185)
Specifications
| Thread / Tubing | ½″ NPT (male) × ½″ OD tube |
|---|---|
| Rotation | 360° swivel |
| Material | Durable metal, corrosion-resistant |
| Typical Use | High-pressure sprayers, proportioners, manifolds, plural-component systems |
Key Features & Benefits
- Leak-free sealing: precision ½″ NPT male threads for reliable connections
- Flexible routing: swivel action reduces stress on tubing
- Durable construction: corrosion-resistant metal
- Compact form factor: ideal for confined manifolds or tight assemblies
- High-pressure performance: suitable for plural-component and airless sprayers
Installation Notes
- Ensure tubing is ½″ OD and compatible with the elbow.
- Apply proper thread sealant or tape on the ½″ NPT male threads.
- Orient the swivel for alignment; avoid over-tightening.
- Inspect regularly for wear in systems with vibration or frequent movement.
Frequently Asked Questions
The 114110 is designed for high-pressure Graco proportioners and plural-component systems. It can handle typical system pressures up to the limits of the connected machine.
Yes, as long as the tubing is ½″ OD and rated for your system’s pressure. The swivel accommodates various tubing types used in Graco systems.
Unscrew the swivel collar to access O-rings for inspection or replacement. Apply compatible grease when reassembling and avoid over-tightening.
Why Choose Genuine Graco Parts?
Using the authentic Graco 114110 ensures compatibility, longevity, and safety in your Graco systems, preventing leaks and premature wear that may occur with non-OEM parts.
