Graco 114135 Manifold Mounting Screw

The Graco 114135 is a durable manifold mounting screw that securely fastens manifolds to pumps or modules, ensuring leak-free and stable operation.

  • Material: Metal, high-strength and corrosion-resistant
  • Function: Secures manifold to pump or module housing
  • Compatible Machines: Graco fluid/airless manifolds, electric/pneumatic modules, and spray/pump systems
  • OEM Quality: Ensures proper fit and reliable operation
  • Maintenance: Inspect and replace if worn, damaged, or corroded

$23.3
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Graco 114135 Manifold Mounting Screw – Overview & Compatibility

The Graco 114135 is a high-quality manifold mounting screw designed to securely fasten manifolds to pumps, modules, or housings, ensuring leak-free and stable operation in Graco systems.

Compatible Machines

  • Graco Fluid / Airless Manifolds
  • Graco Electric / Pneumatic Modules
  • Graco Spray / Pump Systems where a manifold requires secure mounting

Specifications

Part Type Manifold Mounting Screw
Material Metal – high-strength, durable
Function Secures manifold to pump, module, or housing
Durability OEM quality, resists vibration and loosening
Maintenance Inspect for wear, corrosion, or damage; replace if necessary

Key Features & Benefits

  • Secure fastening: Ensures manifold remains properly mounted
  • Durable construction: Metal design resists wear, vibration, and loosening
  • OEM part: Guarantees correct fit and reliability in Graco systems
  • Safety: Properly mounted manifolds prevent leaks or misalignment

Installation & Maintenance

  1. Align manifold properly on pump or module housing.
  2. Insert the 114135 screws into mounting holes.
  3. Tighten screws evenly to manufacturer torque specifications.
  4. Inspect periodically for corrosion, wear, or loosening; replace if needed.

Frequently Asked Questions

The 114135 screw secures the manifold to the pump or module, maintaining stable operation and preventing fluid leaks.

It is used in Graco fluid/airless manifolds, electric/pneumatic modules, and spray/pump systems that require secure manifold mounting.

Inspect the screw periodically for corrosion, wear, or loosening. Replace if damaged or worn to ensure the manifold remains securely mounted.

Why Choose Genuine Graco Parts?

Using the authentic Graco 114135 screw ensures proper fit, secure mounting, and reliable operation of Graco manifold and pump systems, reducing downtime and maintaining safety.
