Graco 17V782 Pressure Control Kit
5/5
(1 review)
$98.12
$107.00
Save 8%
Available to Order
The Graco 17V782 Pressure Control Kit ensures smooth, consistent pressure control and reliable spray performance on compatible Magnum models.
- Fits Magnum X5, X7, LTS 15, LTS 17 & Project Painter Plus
- Includes pressure control, labels, and instructions
- Genuine OEM part – easy drop-in replacement
- Restores stable spraying pressure and performance
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Overview & Key Benefits
Compatible Machines
This kit fits the following Graco Magnum homeowner sprayers that use the diaphragm-style pressure control.
- Magnum X5 (Part No. 262800, Series E)
- Magnum X7 (Part No. 262805, Series D)
- Magnum LTS 15 (Part No. 17K955, Series A)
- Magnum LTS 17 (Part No. 17K960, Series A)
- Magnum Project Painter Plus
What is the Graco 17V782 Pressure Control Kit?
It’s a factory replacement pressure control/switch assembly that regulates output pressure on select Magnum sprayers. A healthy pressure control delivers consistent atomization, reduces overspray, and helps your sprayer start up and prime reliably.
Key Features
- Completely assembled for easy installation
- Provides adjustable spray speeds/pressure for different coatings
- Includes diaphragm pressure control, two labels, and repair manual
- Genuine OEM part for best performance and fit
Kit Details & Specs
| Graco Part Number | 17V782 |
|---|---|
| Kit Type | Pressure Control / Switch Assembly (diaphragm type) |
| Includes | Pressure control (pre-assembled), 2x labels, repair/installation manual |
| Primary Function | Regulates and stabilizes pump pressure for smooth, consistent spray |
| Typical Symptoms Resolved | Erratic pressure, hunting/surging, limited max pressure, poor atomization |
| Compatible Series | Magnum X5, Magnum X7, LTS 15, LTS 17, Project Painter Plus |
| Install Difficulty | DIY-friendly with basic tools; follow model-specific manual |
Installation (Quick Guidance)
Always unplug, relieve pressure, and follow your sprayer’s manual. At a high level:
- Disconnect power and relieve system pressure.
- Remove the old pressure control/switch per your model’s instructions.
- Install the 17V782 assembly, connect wiring as shown in the manual.
- Reapply labels as needed; verify knob rotates freely.
- Prime with water and test for smooth, adjustable pressure.
Frequently Asked Questions
Check your model and series label. 17V782 fits Magnum X5 (262800 Series E), Magnum X7 (262805 Series D), LTS 15 (17K955 Series A), LTS 17 (17K960 Series A), and Project Painter Plus. If your unit differs, consult the parts manual for your exact model/series before ordering.
Surging or hunting pressure, inability to reach target pressure, inconsistent spray fan, and frequent trigger pulsation are common symptoms. Inspect filters, tips, and hoses first; if those are clear, the pressure control may need replacement.
Yes. The box includes a Graco repair/installation manual along with two replacement labels, plus the assembled diaphragm pressure control.
Many users install it with basic tools. Always disconnect power, relieve pressure, and follow the model-specific instructions. If unsure about wiring or disassembly, contact a service center.
Yes, 17V782 is a genuine Graco OEM kit designed specifically for the Magnum series models listed above for best performance and safety.
