Graco 100022 Hex Hd Screw Cap

The Graco 100022 Hex Head Cap Screw is a genuine OEM fastener widely used in Graco equipment for secure and reliable assembly connections.

Thread Size: 1/4-20 UNC × 3/4″ (19 mm)
Head Type: Hex Head — Cap Screw
Material Grade: Grade 5 Steel
Common Use: Mounting brackets, cover supports, and frame hardware
Fits: Graco Standard Elevator (204385, 206231, 207408), Monark, President & Viscount Pumps, OEM Striping Packages

$8.74

Based on 0 reviews

Description

Overview & Compatibility for Graco 100022 — Hex Head Cap Screw

Compatible Machines / Assemblies

This fastener appears in multiple Graco parts lists and assemblies. The following are confirmed usages from Graco manuals (not an exhaustive list):

Standard Elevator units — models 204385, 206231, 207408 (used in the Cover Support Assembly).
Pump mounting brackets for Monark, President and Viscount pump families (various bracket/mount points as specified in those manuals).
Skid-Mount OEM Striping Package assemblies where a ¼-20 UNC × ¾″ cap screw is called out in the parts list.

What is Graco 100022?

The Graco 100022 is a genuine Hex Head Cap Screw used across multiple Graco assemblies (covers, brackets, frames and guards). It provides secure, service-grade fastening to maintain alignment and vibration resistance in professional equipment.

Key Specifications

Graco Part	100022 — Screw, Cap, Hex HD
Thread / Size	1/4-20 UNC (external) × 3/4″ length (≈ 19 mm)
Head Type	Hex Head (cap screw)
Thread Class	UNC-2A (typical per Graco parts listings)
Grade	Grade 5 (where specified in Graco lists)
Typical Use	Cover supports, mounting brackets, guard/frame fastening, general hardware positions calling for 1/4-20 × 3/4″ cap screws

Fitment Notes

Match the thread (1/4-20), length (3/4″), and head style with your manual’s bill of materials.
Some assemblies specify Grade 5; use equal or higher grade where required.
If your unit uses washers/lock-washers or thread-locker, reinstall per the service manual.

What’s Included

1 × Graco 100022 Hex Head Cap Screw

Frequently Asked Questions

Physically it matches the 1/4-20 × 3/4″ spec, but Graco hardware meets OEM grade/tolerance and is validated for the application. For critical assemblies, use genuine Graco 100022 or an exact-spec replacement at the same grade.

Commonly in cover supports, mounting brackets, and various frame/guard positions that call for a 1/4-20 cap screw of 3/4″ length (see your model’s parts diagram).

It may—100022 is a general hardware part used across many models. Check your exact model/serial parts list; if it specifies 100022 or 1/4-20 × 3/4″ hex cap screw (Grade 5), this is the correct item.

Use the same washers/lock-washers and assembly method shown in your parts diagram. If the manual calls for thread-locker, apply the specified type and torque per the service instructions.

Verify the thread (1/4-20), length (3/4″), and grade. If your build sheet calls a different length or grade, match that specification rather than substituting.
