Compatible Machines
Verified models that use the Graco 100960 Low Pressure Air Gauge. Always confirm with your serial/model diagram before ordering.
- Graco 231-133 Pneumatic Cart Mount Pump (Series A)
- Graco 231-135 Pneumatic Cart Mount Pump (Series A)
- Graco 231-145 Pneumatic Cart Mount Pump (Series A)
- Graco 231-173 Pneumatic Cart Mounted Pump (Series A)
- Graco 231-301 Pneumatic Cart Mount Pump (Series A)
This gauge also appears in multiple Graco air regulator assemblies and related pneumatic systems. If your unit’s parts manual lists 100960, this is the correct replacement.
Product Overview
The Graco 100960 Low Pressure Air Gauge is a bottom-mount, diaphragm-type pressure gauge designed for pneumatic circuits on Graco equipment. It provides a clear, reliable reading up to 200 psi (0–14 bar), ideal for monitoring regulator outlet pressure on spray systems and carts.
Key Specifications
| Part Number | 100960 |
| Pressure Range | 0–200 psi (0–14 bar) |
| Mount / Connection | Bottom-mount, 1/4" NPT male |
| Dial Diameter | 2" (≈51 mm) |
| Max Working Pressure | 200 psi (≈1.4 MPa) |
| Application | Air / pneumatic pressure indication (regulator outlet, air manifolds) |
Why choose this gauge?
- OEM-grade fit for Graco pneumatic carts and regulator assemblies
- Clear 0–200 psi scale for low-pressure air control
- Bottom-mount 1/4" NPT threads for common Graco layouts
Fitment Guidance
- Match your parts diagram: look for 100960 in your model’s exploded view.
- If your system specifies a different range or connection (e.g., rear-mount or 1/8" NPT), select that exact spec.
- For regulator kits that list 100960, this gauge is the correct replacement.
Frequently Asked Questions
Air/pneumatic. The 0–200 psi range and OEM usage indicate it’s intended for air regulators and pneumatic circuits on Graco equipment.
The connection is 1/4" NPT (male) with a bottom-mount stem, suitable for typical Graco regulator/manifold ports.
Check your unit’s parts manual or online exploded diagram. If the gauge line item is 100960, this is the correct replacement. When in doubt, share your model & serial for verification.
No. This listing is for the gauge only. Adapters, regulators, or fittings are sold separately unless stated otherwise on your kit page.
