Graco 101088 Screw Mach

The Graco 101088 Screw Mach is an OEM machine-screw fastener used in various Graco sprayer assemblies for frames, covers, and brackets. Reliable and durable for factory-fit fastening.

  • Part Number: 101088
  • Type: Machine screw fastener
  • Use: General hardware in Graco sprayers and accessories
  • OEM Quality: Ensures perfect fit and thread match

$3.22
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Product Overview & Quick Facts

Compatible Machines

Graco 101088 Screw Mach is a machine-screw fastener used across various Graco assemblies (covers, brackets, frames). OEM manuals do not list a single dedicated model family for this part; compatibility is assembly-specific.

  • Check your sprayer’s parts diagram for part 101088 in the exact subassembly.
  • If your manual lists 101088, this is the correct OEM fastener.
  • When a manual shows a “machine screw” with number 101088, this is the direct replacement.

Key Details

Part Number 101088
Item Name Screw Mach (machine screw fastener)
Function General fastening in panels, guards, brackets, frames and similar assemblies.
Thread / Size Not specified in available OEM summaries. Refer to your model’s parts list for exact dimensions.
Where Used Varies by model; appears wherever the manual explicitly calls out 101088.
What’s Included 1 × Graco OEM machine screw (quantity per your cart).

Why Choose the OEM Screw

  • Correct fit when your manual specifies 101088.
  • Consistent clamping for covers/frames—helps prevent vibration-related loosening.
  • Saves time: no cross-matching or guessing thread/pitch from hardware equivalents.

Installation Notes

  • Match the length, thread, and head style shown in your parts diagram.
  • Hand-start to avoid cross-threading; then tighten to the assembly’s spec.
  • Use medium threadlocker only if the manual recommends it.
  • Replace any companion washers or clips if the diagram lists them as separate parts.

Frequently Asked Questions

It denotes a machine screw—a standard fastener used in threaded metal parts. It’s specified by OEM diagrams for exact assemblies.

Usage is assembly-specific. Check your exact model’s parts manual and search for 101088; if listed, this is the correct OEM fastener for that location.

Only if you match thread, length, and head style exactly and your manual does not prohibit substitutions. OEM is recommended to ensure proper fit and torque.

Refer to the service manual for your machine or the specific assembly note. If not listed, tighten to typical machine-screw practice and re-check after initial run-in.

Order the specified washers/spacers as separate items to maintain correct stack height and clamping force.
