Graco 15M050 Spring Pilot Upper

The Graco 15M050 Pilot Upper Spring ensures consistent pressure regulation and smooth operation in pump systems.

  • OEM pressure control spring
  • Ensures smooth actuation of pilot valve
  • Durable metal construction
  • Helps maintain system efficiency

$5.67
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Graco 15M050 Spring, Pilot Upper

Compatible Machines

  • Graco Ultra Max II 695
  • Graco Mark V ProContractor

Key Features

Feature Description
Precision Spring Rate Ensures correct pressure set point in pilot valve assembly.
OEM Metal Construction Resists fatigue from repeated cycles.
Consistent Performance Maintains smooth operation under load.
Direct Replacement Fits Graco control assemblies without modification.

Installation & Usage Tips

  • Ensure machine is shut off and depressurised before service.
  • Remove old spring carefully and position new one according to manual.
  • Check valve seating and actuator movement after install.
  • Monitor system for any pressure fluctuation after replacement.

Frequently Asked Questions

Erratic pressure control, inconsistent spray output or unusual valve noise may indicate spring fatigue.

Use only the OEM spring unless the manual specifies a different rate; changing spring rate can affect performance and warranty.

Inspect during each major service; replace if signs of fatigue, corrosion or inconsistent pressure control are found.
