Graco 102472 Rivet

The Graco 102472 Rivet is a genuine OEM blind rivet designed for secure one-side fastening in Graco sprayer assemblies such as the EH 433 series.

  • Part Number: 102472 (Blind Rivet)
  • Fits: EH 433 – Models 231-004, 226-433, 226-432
  • Use: Shield/guard and cover fastening
  • OEM Quality: Ensures exact fit and durability

$7
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Genuine Blind Rivet for Graco Assemblies – Part 102472

Compatible Machines

  • Graco EH 433 – Model 231-004 (Series A)
  • Graco EH 433 – Model 226-433 (Series M)
  • Graco EH 433 – Model 226-432 (Series K)

Key Details

Part Number Graco 102472 (sometimes shown as 102-472)
Description Rivet, blind — one-side installation fastener used in Graco equipment.
Typical Location Often used around shield/guard or cover assemblies on select sprayers (e.g., EH 433 series).
OEM Status Genuine Graco OEM replacement hardware for proper fit and retention.
Size/Material Dimensions/material not specified in public summaries—consult your model’s service parts manual if exact diameter/grip length is required.
Also Listed As “RIVET, blind” in parts lists; may appear under fasteners in exploded views.

What the Graco 102472 Rivet Does

The Graco 102472 Rivet is a blind rivet designed for secure fastening where back-side access isn’t available. Using the OEM rivet helps maintain assembly integrity and safety, especially on shield/guard components that protect moving parts.

Why Choose the OEM Blind Rivet?

  • Exact fit for listed models and assemblies.
  • Reliable retention under vibration and jobsite use.
  • Service-friendly—the correct rivet simplifies future maintenance.

Installation & Usage Tips

  • Use a compatible blind-rivet tool sized to the correct diameter/grip range for your machine’s hole spec.
  • Replace any distorted or drilled-out rivets during guard removal/reinstall.
  • Confirm hole size and stack thickness in your service parts manual before installation.

Frequently Asked Questions

A blind rivet installs from one side of the joint—ideal where the back side is inaccessible (e.g., enclosed guards or housings).

Using the OEM rivet ensures correct fit, grip range, and material compatibility for Graco assemblies. A non-OEM substitute may not hold properly or could affect safety and serviceability.

It’s commonly referenced around the shield/guard area in the EH 433 parts lists. Check your machine’s exploded view to confirm exact placement.

Yes—when installing. If your manual doesn’t list it, measure the hole size and material stack thickness, or consult a Graco service parts manual for your exact model/series.

It may fit other models using the same guard/cover assembly. Verify by checking your model’s parts list for “RIVET, blind” with part number 102472 (or 102-472).
