Graco 16H295 Locking Ring

Graco 16H295 Locking Ring – Genuine Replacement Component

Compatible Machines

This Graco 16H295 Locking Ring is used in several Graco spray guns and assemblies that require a secure locking interface for angled adapters and connection fittings.

• Graco Fusion AP Spray Gun (15B215)
• Graco Fusion MP Spray Gun
• Graco Fusion PC Spray Gun

Product Details

The 16H295 Locking Ring is designed to secure an angled adapter or connection fitting in place, ensuring tight and stable assembly during operation. It prevents loosening caused by vibration and maintains proper alignment of components within the spray gun or drum-mounted adapter setup. This ring is commonly used in Fusion-series spray guns and in systems utilizing angled drum adapters.

Key Features

• Durable construction suitable for industrial spray environments.
• Provides firm locking to prevent adapter rotation or loosening.
• OEM replacement part for accurate fit and dependable performance.
• Used across multiple Fusion-series spray gun models.

Usage Notes

Always ensure the adapter and drum surfaces are clean before installation. Thread the ring fully until contact is made with the drum or housing. Replace if wear, thread damage, or deformation is visible.
