Graco 248189 Fan Motor Repair Kit
4/5
(1 review)
$31.85
$33.70
Save 5%
In Stock
Graco 248189 Fan Motor Repair Kit keeps your sprayer’s motor cool and running efficiently by replacing a worn or damaged fan assembly.
- OEM replacement for Ultra 395 PC and 595 Series sprayers.
- Includes motor fan blade and retainer hardware.
- Restores proper airflow to prevent overheating.
- Easy to install with standard tools.
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Cooling Fan Kit Overview & Fitment
Graco 248189 Fan Motor Repair Kit (often listed as fan, motor) is the OEM cooling fan assembly used on select Graco electric airless sprayers. It restores proper airflow across the motor to prevent overheating and extends motor life. The kit typically includes the fan blade and the retaining hardware needed to complete the repair.
Compatible Machines
- Graco Ultra 395 PC — Stand (17E844)
- Graco Ultra 395 PC — Lo-Boy (17E845)
- Graco Ultra 395 PC — Hi-Boy (17E846)
- Graco 595 Proformance Max — Lo-Boy (234589)
- Graco 595 Proformance Max — Hi-Boy (234590)
- Graco Super NOVA 595 — Lo-Boy (826052)
- Graco Super NOVA 595 — Hi-Boy (826046)
- Graco Hi-Boy Ultra 595 (234435)
- Graco Ultra Max II 490 — Hi-Boy
Key Features
- Direct-fit OEM motor fan for reliable cooling performance.
- Helps prevent thermal shutdowns and premature motor wear.
- Simple installation with basic hand tools.
- Ideal preventive replacement when the original fan is cracked or noisy.
Specifications
| Part Number | 248189 |
|---|---|
| Item Type | Fan Motor Repair Kit (listed as fan, motor) |
| Function | Draws cooling air over the motor to dissipate heat during operation. |
| Includes | Motor fan blade and typical retaining hardware (e.g., clip/fastener). |
| Compatibility Notes | Fits selected Ultra 395 PC, 595 series variants, and certain Ultra Max II 490 units (see list above). |
| When to Replace | Fan cracked, missing blades, excessive vibration/noise, or recurrent thermal shutdowns. |
Install & Care Tips
- Disconnect power and allow the sprayer to cool before service.
- Remove shrouds/guards as needed, swap the fan, and secure the retainer per your model’s manual.
- Spin by hand to confirm free rotation and no shroud contact before powering up.
- Keep vents clear of debris to maintain airflow.
Frequently Asked Questions
Yes- this kit is used on Ultra 395 PC Stand (17E844), Lo-Boy (17E845), and Hi-Boy (17E846). If your model number matches, you’re good to go.
Cracked or missing fan blades, scraping noises, vibration, or frequent thermal shutoffs during use. Replacing with the Fan Motor Repair Kit restores proper airflow.
Typically yes-the kit includes the fan and the standard retainer/clip used to secure it. Re-use any model-specific shrouds or screws as required.
Match your sprayer’s model number and type (Stand/Lo-Boy/Hi-Boy) against the Compatible Machines list above, or check your unit’s parts manual for “fan, motor” with part 248189.
4
1 review
1
0%
2
0%
3
0%
4
100%
5
0%
S
Samuel H.
This was a straightforward swap - this 248189 Fan Motor Repair Kit and it fit perfectly with no modifications needed. Part #248189 matched exactly. Customer support was helpful when I had questions about fit.
