Graco 287054 Crankshaft Repair Kit
$93.18
$104.00
Save 10%
In Stock
Graco 287054 Crankshaft Repair Kit is a genuine OEM replacement designed to restore power and smooth performance in Graco electric airless sprayers. Ideal for maintenance or full drive rebuilds.
- Fits models: 395, 490, 495, 595
- Compatible with Ultra, Nova, Ultimate MX II, Ultra Max II series
- Ensures quiet operation and consistent spray pressure
- High-quality Graco OEM build for durability
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Overview: Genuine Graco 287054 Crankshaft Repair Kit
Graco 287054 Crankshaft Repair Kit restores the drive mechanism in popular small-to-mid size Graco electric airless sprayers. It replaces worn crankshaft components to bring the pump back to smooth, reliable operation.
Compatible Machines
This kit fits the following Graco models/series (stand, Lo-Boy, and Hi-Boy variants where applicable):
- Ultra 395
- Nova 395 (Stand / Lo-Boy / Hi-Boy)
- Ultra 495 (Stand / Hi-Boy)
- Super Nova 495 (Lo-Boy / Hi-Boy)
- Ultimate MX II 490 (Lo-Boy / Hi-Boy)
- Ultimate MX II 495 (Lo-Boy / Hi-Boy)
- Ultra Max II 490
- RentalPro 210
Key Benefits & Features
- OEM quality for perfect fit and long service life.
- Restores smooth reciprocating motion for consistent spray pressure.
- Helps reduce vibration, noise, and premature wear on connected drive parts.
- Designed for the widely used 395 / 490 / 495 class Graco sprayers.
Technical Details
| Part Number | 287054 |
|---|---|
| Part Type | Crankshaft Repair Kit (drive/crank assembly components) |
| Brand / Origin | Graco – Genuine OEM replacement |
| Compatible Series | Ultra 395, Nova 395, Ultra 495, Super Nova 495, Ultimate MX II 490/495, Ultra Max II 490, RentalPro 210 |
| Typical Application | Restores the crank/gear that converts motor rotation into pump reciprocation |
| What’s Included | Crankshaft repair components as specified by Graco for PN 287054 (contents may vary by revision) |
| Notes | Verify your sprayer model and part list before ordering; use with matched pump/drive components |
Installation & Use Tips
- Disconnect power and depressurize the sprayer before service.
- Inspect related wear items (bearings, seals, connecting rod) and replace as needed.
- Apply appropriate assembly grease and torque fasteners to spec.
- After installation, run water or test fluid to confirm smooth, even operation.
Frequently Asked Questions
Check your sprayer’s parts manual or model tag against the Compatible Machines list above. If your exact model/variant appears there, this is the correct Crankshaft Repair Kit.
Irregular pressure, noisy operation, vibration, or excessive play in the drive can point to a failing crank/gear. Inspect before damage transfers to rods, bearings, or the pump lower.
Contents are defined by Graco for PN 287054 and may vary by revision. Review the “What’s Included” line in your parts diagram; replace any related bearings/seals if worn.
Yes. The 287054 Crankshaft Repair Kit is an OEM part engineered by Graco for the models listed.
Keep the sprayer clean, use proper filtration, follow recommended lubrication practices, and periodically check fastener torque and play in the drive assembly.
