Graco DutyMax DH230 HD Procontractor Spray Gun & Hose

Graco DutyMax DH230 HD ProContractor Spray Gun & Hose Factory-Fresh, Field-Ready

Don’t let a blown hose or tired gun stall a six-man crew. The diesel-hydraulic Graco DutyMax DH230 HD ProContractor pushes thick intumescent coatings at up to 3300 psi through tips to .039-in. A single pinhole leak or worn needle can halt that fireproofing schedule cold. Smart contractors rely on SprayersAndParts.com for factory-serialized graco parts that swap in minutes, preserve warranty, and get revenue flowing again.

Stay Job-Ready with Long-Life Graco DutyMax DH230 HD Spray Gun & Hose Components

Our most-ordered kit pairs a Contractor PC airless gun and a BlueMax II 3/8 in × 50 ft hose (240797) rated at 3300 psi and 180 °F. The whip-ready hose core resists solvent swell, while the gun’s modular cartridge swaps a worn needle in 60 seconds no bench vice, no special tools.

Five Reasons Pros Buy Genuine

• True 3300 psi burst margin. Each BlueMax II hose is hydro-tested to 5000 psi (150 % of working pressure) before it leaves the factory.
• Viton + PTFE seals. Contractor PC gun seals shrug off hot solvent blends that shred nitrile knock-offs.
• 50 % lighter trigger pull. The gun’s SmartTrigger spring cuts fatigue on all-day roof jobs game-changer when running a graco drywall skimming blade in the other hand.
• Color-match rebuild cartridges. Swap a red (.017) or blue (.021) seat in under a minute.
• Full Graco warranty.

Key Specs at a Glance

One Kit Many Compatible Rigs

Because Graco standardizes threads and pressure ratings, this gun-and-hose combo drops into a surprising number of sprayers, slashing inventory clutter:

• DutyMax GH230 / EH230 / DH300—identical 3/8 in outlet, 3300 psi system.
• GMax II 7900 gas frame—swap directly for texture or block-filler days.
• Ultra Max II 795 / 695 ( 2.2 hp electric )—same BlueMax hose rating and Contractor PC seats.
• LineLazer 3400 stripers—filter, seat and swivel all match graco 495 paint sprayer family rigs.
• Magnum X7 & Project Painter Plus—use RAC X tip guard; see graco magnum project painter plus parts diagram for thread adapter 17M223.

Smart Add-Ons for a Bullet-Proof Fluid Path

1. BlueMax II 3 ft Whip (25C827). A 1/8-in micro-hose at the gun cuts wrist torque and dampens pressure spikes ideal for overhead work.
2. RAC X LP & FFLP Tips. Twelve low-pressure patterns slash overspray 50 % and extend hose life by reducing amp-draw-induced surges.
3. Quick-Flush Valve. Plug in a garden hose, back-flushing the pump and hose in 60 sec perfect when spec calls for a graco extension tools boom.
4. Ground Strap Kit. Stops static arcs when spraying silica-filled elastomerics or heavy iron-oxide primers.
5. Contractor PC Repair Cartridge (17Y297). Keep one in the gang box; swap an entire needle, spring & seat mid-shift no bench vise.

Field-Proven Maintenance Blueprint

1 — Log Hose Hours. Swap at 500 gal latex or 250 gal roof mastic.
2 — Flush Warm. 40 °C water dissolves acrylic twice as fast; half-pressure back-flush keeps grit from the transducer.
3 — Lube the Rod. Two drops TSL every coffee break keeps seats mirror-bright.
4 — Re-Torque Weekly. Gun handle 17 N·m; swivel 20 N·m.
5 — Stock Redundancy. One $70 hose + $200 gun kit saves a $5 000 shift carry two per crew.

Add to Cart, Track, Spray

Open our site, check the gun kit, hose length and whip bundle, then smash Add to Cart. One freight fee, one tracking link, one bullet-proof fluid path see you on tomorrow’s job-site.
