Explore OEM Graco RentalPro 230ES Airless Paint Sprayer Series parts
Graco RentalPro 230ES earned its name by surviving thousands of weekend warriors at national rental counters—then turning around and spraying another decade for professional crews. Under the rugged cage sits a ¾-hp TEFC DC motor that pushes 0.65 gpm at 3 200 psi through a 0.021″ tip, powered by a direct-drive Advantage™ gear set Graco warranties. What keeps that performance profitable is the ability to drop in a fresh Endurance™ pump, swap a gun cartridge in minutes, or click on low-pressure RAC X tips when overspray rules tighten.
Why Choose Genuine 230ES Parts Over Clone Copies?
- Chromex-plated piston & V-Max Blue™ packings—twice the life of bare steel, rated 700 gal latex before first repack.
- SmartControl 1.0 electronics keep fan width within ±1 % at any pressure; aftermarket sensors can “hunt” and waste paint.
- ProConnect™ door pops the pump in 60 s—no bench-vise drama on a client’s driveway.
- BlueMax II hose capacitance feeds true pressure to the board; cheap hose can trip low-pressure alarms.
- Warranty—Backed by Graco.
Key Technical Specs
| Metric |
Value |
| Max Working Pressure |
3 200 psi / 220 bar |
| Max Flow Rate |
0.65 gpm / 2.5 l min |
| Max Tip Size |
0.021″ (single gun) |
| Motor |
¾-hp brushless DC, Advantage™ gear train |
| Frame Weight |
42 lb / 19 kg (Lo-Boy) |
| Power Draw |
12 A @ 120 V—runs on 2 500 W generator |
Sprayers & Accessories That Share 230ES DNA
- Magnum Pro X7 / LTS 17—identical piston and seat diameters; LP RAC X tips screw straight in to control overspray.
- Magnum X5 / LTS 15—shares gun filters, ¼″ hose threads and most graco paint sprayer accessories.
- Ultra 395 PC—the Endurance lower bolts on; keep one spare pump for both rigs.
- FieldLazer S100—ball/seat kit and RAC X tips match, letting you stripe sidelines after house jobs.
- Graco Cordless Ultra guns—use the same RAC X LP deck-stain tips on trim touch-ups.
Top-Moving OEM Parts & Upgrades
- 246-349 Endurance Pump Lower—Chromex rod + pre-packed seals, installs blindfolded with ProConnect.
- 17Y-297 Contractor PC Gun—four-finger adjustable trigger; full breakdown inside our graco gun parts diagram.
- 240 794 BlueMax II 50-ft Hose—¼″ ID, 3 300 psi, dual swivel—pair with a 3-ft whip for wrist relief.
- 17G-180 RAC X LP 517 Tip + Guard—spray 500 psi lower for 18 % paint savings on walls.
- Easy-Out 60-mesh Filter Core—bleeds inside-out to slash flush time; swap to 100-mesh for enamels.
- Pump Armor™ 1 gal—seals packings for off-season storage; mandatory in humid shops.
Field-Proven Maintenance Blueprint
- Warm Flush—100 °F water dissolves latex 30 % faster; safe for BlueMax liners.
- Log Hours on Frame—Sharpie pump hours weekly; repack at 500 h latex, 250 h block filler.
- Colour-Code Bins—blue = electric, red = gas, green = texture; no more wrong-kit grabs.
- Rotate Hose Ends Weekly—evens liner wear and holds SmartControl pressure accuracy.
- Keep a graco Gun Repair Kit onsite—cartridge swap takes five minutes, saves a crew hour.
Frequently Asked Questions
Will 230ES parts fit my Magnum X7?
Yes—LP tips, guards, gun filters and ¼″ hoses thread in; keep pump pressure ≤ 2800 psi.
Longest hose run recommended?
150 ft total: 3⁄8″ BlueMax for first 100 ft, ¼″ for last 50 ft; maintain 2800 psi at a 0.019″ tip.
Seat material for solvent enamel?
Stick to carbide seats; stainless pits after 150 gal xylene-based coatings.
Ready to Swap Out Downtime for Billable Spray Time? Add a 246-349 pump, LP tip pack, and BlueMax hose to your cart now. We’ll ship —tomorrow the 230ES goes back to printing profit.
