Graco 2005276 Fluid Filter Manifold Outlet Packless Plug 3/8 XT

Graco 2005276 Outlet Fluid Filter 3/8" XT High Performance is a precision engineered fluid filtration component built for professional airless sprayer systems. Designed to ensure a smooth, contaminant-free flow, it delivers consistent material output and protects your sprayer from clogs or uneven spray patterns.

Compatible With: Graco XT Mark IV, Pro Hi-Boy Sprayers, and XT Series Pumps
Integrates seamlessly with Graco texture sprayer guns and high-pressure coating systems
Features a durable 3/8" XT connection for leak-free, high-performance operation

Ideal for contractors and finishing professionals who demand cleaner flow, greater efficiency, and longer equipment life under high-pressure applications.

Retail Price: $46.4

You save: $2.55 (5.50%)

Our Price: $43.85

Based on 0 reviews

Description

Overview: Graco 2005276 Outlet Fluid Filter 3/8" XT High Performance

Compatible Machines

Verified XT-platform models that accept the 3/8" XT outlet filter / packless plug interface:

Graco XT Mark IV Pro Hi-Boy (filter breakdown lists 2005276)
Graco Mark V XT ProContractor Hi-Boy (parts list references 2005276 “plug/3/8 XT” on this platform)

What it is

Graco 2005276 is an Outlet Fluid Filter 3/8" XT High Performance for XT-series sprayers. It sits at the sprayer’s outlet/manifold to capture debris before the hose and gun, helping prevent tip clogs, reduce wear, and maintain finish quality. Some Graco and distributor catalogs also refer to the 3/8" XT outlet piece as a “Plug, Packless, 3/8 XT”—the interface used in the same outlet filter assembly on the XT platform.

Key Benefits

Designed for XT-platform sprayers using a 3/8" outlet manifold/filter housing
Helps protect pumps and spray tips by trapping contaminants at the outlet
Supports consistent spray pattern and finish quality on architectural coatings

Technical Summary

Part Number	2005276
Function	Outlet Fluid Filter / XT outlet manifold interface (3/8")
Platform	XT High Performance sprayers (selected models)
Outlet Size	3/8" XT
Typical Working Pressure	Up to 3300 psi (matches XT sprayer ratings; confirm for your exact model)
Position in System	Manifold / pump outlet filtration, upstream of hose & gun

Fit tip: If your XT sprayer uses a 3/8" outlet filter manifold (e.g., XT Mark IV/Mark V configurations), 2005276 is the referenced outlet filter/plug interface. Models that use a 1/4" XT outlet typically require a different part.

Frequently Asked Questions

Check that your machine is an XT model using a 3/8" outlet manifold. Confirm against your unit’s parts breakdown. Verified examples include XT Mark IV Pro Hi-Boy and Mark V XT ProContractor Hi-Boy.

On XT platforms, the 3/8" outlet filter assembly may be referenced as a packless plug component in some catalogs. It denotes the same 3/8" XT outlet interface within the outlet filter/manifold assembly for the models listed above.

XT architectural sprayers commonly operate up to 3300 psi. Always follow your sprayer’s manual and parts list to ensure the outlet filter matches the unit’s rated pressure and thread standard.

Match your sprayer’s exact model and build (Standard/ProContractor/Hi-Boy) to its official parts breakdown. Look for 2005276 in the outlet filter/manifold section and verify the 3/8" XT designation.
