Graco 238564 Q Filter, M&L
$12.60
Available to Order
The Graco 238564 Q Filter, M&L is a 60-mesh tip filter that helps prevent clogging and ensures a smooth, consistent spray finish. Ideal for contractors using Graco airless spray guns with dripless tip guards.
- Mesh Size: 60-mesh (coarse) for latex and primers
- Fits: Graco guns with in-guard tip filters
- Part Number: 238564
- Package: Multipack (often 25 per pack)
- Purpose: Filters debris before paint reaches the tip
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Graco 238564 Q Filter, M&L – 60-Mesh Tip Filter (Multipack)
Compatible Machines / Systems
This Graco 238564 Q Filter, M&L is a 60-mesh tip filter designed for Graco airless setups that use an in-guard tip filter. Compatibility depends on the tip guard used on the gun.
- Graco airless spray guns equipped with the Dripless™ Tip Guard that accepts in-guard tip filters (fits inside the guard before the tip).
- Graco automatic / protective-coatings airless guns whose parts lists specify 238564 (60-mesh) tip filter.
- Most contractor-grade Graco airless systems when paired with the matching Graco dripless tip guard adapter.
What it is & why it’s used
The 238564 (Q Filter, M&L) is a coarse 60-mesh spray tip filter that sits inside the tip guard to catch debris right before the tip—reducing tip clogs and improving finish quality.
Key Specs
| Graco Part # | 238564 |
|---|---|
| Type | Tip filter (in-guard) |
| Mesh / Coarseness | 60-mesh (coarse) – common for latex/primers |
| Package | Multipack (often supplied in 25-count) |
| Fitment Note | Works only with compatible Graco dripless tip guard/adapter that accepts in-guard filters |
Usage Tips
- Install the filter inside the tip guard with the open end toward the fluid flow per your gun/guard manual.
- Use 60-mesh for most latex/primer; move to finer mesh when spraying thinner coatings.
- Inspect and replace regularly—clogged or damaged filters cause pressure spikes and poor finish.
Frequently Asked Questions
Fitment is based on the tip guard on your gun—not the pump. If your gun uses a Graco Dripless™ Tip Guard (in-guard filter style), the 238564 (60-mesh) is typically the correct filter. Always verify in your gun/guard manual or parts list.
60-mesh (coarse) is commonly used for latex paints and primers. For thinner coatings (lacquers, stains), your setup may call for a finer mesh—check the material spec and Graco’s tip/filtration guide.
It’s commonly supplied as a multipack (often 25 filters per pack). Some distributors may offer alternate pack sizes; check the listing on your product page.
Look inside the tip guard for a filter recess. Your gun/guard manual or parts diagram will list a “tip filter” and often specify 60-mesh with part 238564 for compatible models. If the diagram shows no in-guard filter, this part will not fit.
This filter is designed for Graco dripless tip guard/adapter systems. Using other brands/guards isn’t guaranteed to fit or seal correctly—stick to the matching Graco guard for best results.
