Graco 113958 External Retaining Ring

The Graco 113958 External Retaining Ring secures shafts and components, ensuring proper alignment and reliable operation in compatible sprayers and dispensers. Key features include:

  • External snap ring for axial retention
  • Durable steel construction for mechanical reliability
  • OEM part for ThermoLazer, ProMelt, and Glass Bead Dispense systems
  • Prevents component movement and maintains assembly stability

$6.3
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Graco 113958 – External Retaining Ring Overview

Compatible Machines

The **113958 External Retaining Ring** is designed to secure shafts and assemblies in several Graco spray and dispensing systems. Verified compatible machines include:

  • Graco ThermoLazer / ProMelt 24H624
  • Graco ThermoLazer 200, 200TC, and 300TC models
  • Graco Glass Bead Dispense Kits (Manual 334145B)

Key Features

  • External **retaining ring** (snap ring / circlip) for axial retention
  • OEM part ensuring proper fit and mechanical reliability
  • Holds components on shafts and housings in place
  • Durable steel construction suitable for high-load applications

Technical Specifications

Part Number 113958
Type External Retaining Ring
Material Steel (OEM)
Dimensions Height: 0.6 in, Length: 2.4 in, Width: 2.95 in (approx.)
Application Securing shafts, arms, and housings in Graco sprayers and dispensers

Applications

The 113958 External Retaining Ring is ideal for:

  • Axially securing shafts and components in ThermoLazer and ProMelt sprayers
  • Maintaining assembly alignment in Glass Bead Dispense Kits
  • Replacing worn or damaged retaining rings to restore mechanical stability

Installation Tips

  • Verify groove size matches the 113958 retaining ring
  • Use proper snap-ring pliers for installation to avoid deformation
  • Inspect grooves for wear or damage before installing the ring

Frequently Asked Questions

The 113958 External Retaining Ring holds components such as shafts, arms, and housings in place, ensuring proper axial alignment and preventing movement in Graco sprayers and dispensers.

It is intended for specific ThermoLazer, ProMelt, and Glass Bead Dispense models. Always verify compatibility against your machine’s parts diagram before installation.

The ring measures approximately 0.6 in in height, 2.4 in in length, and 2.95 in in width, suitable for its intended shaft and housing grooves in compatible machines.
