Graco AAM109 Air Assisted Paint Spray Tip

The Graco AAM109 Fine Finish Tip delivers precise atomization with a narrow fan, perfect for detailed and low-to-medium pressure finishes.

  • Fits: Graco G15 & G40 Air-Assist Guns
  • Orifice: 0.009 in (0.229 mm)
  • Fan Width: 2–4 in @ 12 in distance
  • Best For: Lacquers, stains, thin coatings
  • Design: Air-assisted fine finish for detailed work

Retail Price: $149.5
You save: $5.97 (3.99%)
Our Price: $143.53
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Graco AAM109 Fine Finish Tip — Compatibility & Technical Overview

The Graco AAM109 Fine Finish Tip is a precision flat tip engineered for very fine atomization with a narrow fan, ideal for detailed and low‑to‑medium pressure finishing applications. ([turn1search4](#))

Compatible Machines

  • Graco G15 Air‑Assist Spray Guns – Manual high‑quality finish guns designed for AAM fine finish tips such as the AAM109. ([turn1search2](#))
  • Graco G40 Air‑Assist Spray Guns – Manual or automatic air‑assist guns that accept AAM series tips. ([turn1search2](#))

Technical Specifications

Part Number AAM109
Orifice Size 0.009 in (0.229 mm)
Fan Width 2–4 in (50–100 mm) @ 12 in distance
Design Air‑assisted Fine Finish Pin Tip
Best For Very fine detail finish on lacquers, stains, and thin coatings

Key Benefits

  • Precision Atomization: Narrow 2–4 inch fan provides detailed, smooth finishes on small surfaces. ([turn1search4](#))
  • Fine Finish Output: Excellent for light, detailed work with thin materials. ([turn1search7](#))
  • Air‑Assist Compatibility: Designed for use with Graco air‑assist guns for reduced overspray and better control. ([turn1search2](#))

Frequently Asked Questions

The AAM109 tip has a 0.009 in (0.229 mm) orifice with a narrow 2–4 inch fan, ideal for very fine detail work. ([turn1search4](#))

This tip is optimized for thin to medium coatings; thicker materials may require a larger orifice tip for proper flow and coverage.

Yes — the AAM109 fits Graco G15 and G40 air‑assist spray guns designed for AAM series tips. ([turn1search4](#))
