Graco 114530 Honda 5.5 HP Gasoline Engine
The Graco 114530 Engine is a genuine, factory‑matched 5.5 HP Honda gasoline powerplant used in a range of Graco walk‑behind and carted machines. Designed to provide reliable start-up and consistent power, it restores original performance for machines that specify this part.
Compatible Machines
- GMAX II 5900 Convertible / Standard / Lo‑Boy
- Line Driver (walk‑behind striper)
- LineLazer IV 5900
- LineLazer III 200HS
Key Features
- OEM Graco engine – guaranteed fit and compatibility
- Powered by a **Honda 5.5 HP** gasoline motor for proven reliability :contentReference[oaicite:5]{index=5}
- Ready to install – includes necessary mounting components in Graco‑spec setup
- Designed for durable and consistent power delivery in striping or spraying applications
Where It’s Used
This engine assembly is specifically referenced in Graco parts and service manuals for several Graco machines. For example:
- The **GMAX II 5900** parts sheet lists 114530 as its engine. :contentReference[oaicite:6]{index=6}
- In the **Line Driver** repair manual, 114530 is the engine reference. :contentReference[oaicite:7]{index=7}
- The **LineLazer IV 5900** technical parts list includes 114530 for that model. :contentReference[oaicite:8]{index=8}
- The **LineLazer III 200HS** parts diagram also shows 114530 as its 5.5 HP Honda engine. :contentReference[oaicite:9]{index=9}
Why Replace It
If your current engine is underperforming, sluggish, hard to start, or damaged, replacing with the genuine 114530 ensures:
- Proper power output matching the machine’s design
- Maintained warranty or service compatibility
- Reduced risk of misfit or mechanical failure compared to using non‑OEM engines
Installation Advice
- Turn off the machine and relieve any pressure before removing old engine.
- Ensure correct torque on mounting bolts as per Graco spec.
- Connect fuel, throttle, and ignition wiring carefully — follow machine’s service manual.
- After install, run the engine at idle to check for vibration or misalignment.
Q: How do I confirm my machine uses part 114530?
A: Check your machine’s parts manual or service diagram — if the parts list shows “114530 Engine, gas, 5.5 HP, Honda”, this part is correct. Manuals for GMAX II 5900, Line Driver, and LineLazer IV 5900 all reference it. :contentReference[oaicite:10]{index=10}
While technically possible, using it on non‑Graco machines may require custom mounts or wiring. It’s recommended to use this engine only in Graco models that officially support part 114530 for safety and compatibility.
If you use the genuine **Graco 114530** engine, you maintain correct OEM specifications. However, always check with Graco or your service provider about warranty terms when replacing major components.
