Graco 100004 Screw Cap Hex Hd

The Graco 100004 Screw, Cap, Hex Head is a genuine hardware fastener designed for secure mounting and frame assembly across multiple Graco systems.

  • Used in GrindLazer, Striping, and Extruder systems
  • OEM-grade hex-head cap screw for structural stability
  • Durable and corrosion-resistant material
  • Check your IPL for exact fit and thread size

$12.26
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Detailed Overview: Graco 100004 – Screw, Cap, Hex Head

Compatible Machines / Systems

This genuine Graco 100004 hex-head cap screw is used across multiple assemblies. Confirm with your unit’s parts manual before ordering.

  • GrindLazer Scarifier Series — models 270, 390, 480 (various revisions)
  • Skid-Mount OEM Striping Package assemblies
  • Bulldog (4:1) Circulation Packages / Circulation Frames
  • 1:1 Extruder / Air-Powered Ram systems and related platen mounting kits

What is it?

Graco part 100004 is a SCREW, CAP, HEX HD (hex-head cap screw) used as original hardware in various Graco equipment frames, guards, mounts, and accessory sub-assemblies.

Part # Official Name Typical Use Notes
100004 SCREW, CAP, HEX HD Mounting plates, guards, frames, ram plates, circulation/striping/skid assemblies, GrindLazer chassis points Verify thread size & length per your model’s IPL (parts manual) before purchase.

Fitment Guidance

  • Hardware specs (thread, length, grade) can vary by assembly. Always match the 100004 listing in your exact model’s parts diagram.
  • Replace in sets where applicable (e.g., matched screws with their washers/locknuts) to maintain clamping force and safety.
  • Use genuine or equivalent-grade hardware to preserve equipment integrity and alignment.

Quick Specs & Logistics

Graco Category Hardware — Hex-Head Cap Screw
Material / Grade Industrial fastener; use same grade as specified in your unit’s IPL (e.g., Grade 5 in many assemblies)
Common Mates Often paired with flat washers and locknuts in Graco frames/guards (check your diagram)
Typical Locations Motor mounts, guard covers, manifold/ram plate mounts, circulation frame members, skid bases
Ordering Unit Sold individually (EA)

Frequently Asked Questions

Open your model’s Illustrated Parts List (IPL) and search for 100004. Match the quantity, location, and any listed size/grade to your assembly before ordering.

In Graco manuals, 100004 appears as a hex-head cap screw specified for different assemblies. Thread/length can be called out within those assemblies. Always follow your specific IPL call-out for exact size.

If your IPL shows 100004 with specific flat washers and locknuts, replace them together to maintain proper clamping and vibration resistance.

Yes—100004 is a genuine Graco part number used in factory parts lists. Always purchase from trusted sources to ensure authenticity.

Only if it exactly matches the size, thread, length, and strength grade specified by your IPL. For safety-critical points (guards, frame mounts), OEM is strongly recommended.
