Graco 15D560 Manifold Assembly 120V

Graco 15D560 Manifold Assembly (120 V) — Detailed Description

The Graco 15D560 manifold assembly is a genuine OEM module designed for use in 120 V electric sprayer systems. This assembly integrates key flow‑control valves, sensor ports and plumbing interfaces into one compact unit, making it ideal for efficient fluid distribution and reliable operation in professional spray finishing applications.

Key Features & Benefits

• Factory‑specified OEM manifold assembly engineered for Graco sprayers with 120 V supply.
• Combines multiple valves and sensor interfaces in a single assembly to reduce installation complexity and leakage points.
• Built from durable materials to handle frequent cycles, harsh spray environments and high‑use conditions.
• Precise fluid routing supports consistent pressure, optimal flow rates and better equipment uptime.
• Simplified replacement part helps reduce downtime: install the 15D560 manifold assembly rather than servicing multiple independent valves.

Compatibility & Application

The 15D560 manifold assembly is listed for use in Graco texture and finishing sprayer models that operate on 120 V electrical systems. It is especially relevant when fluid manifold functionality, sensor integration and reliable fluid routing are required.

Technical Specifications

Installation & Maintenance

1. Switch off the sprayer and disconnect power before performing any service.
2. Access the manifold assembly location—typically near fluid pump or control manifold region in the sprayer.
3. Disconnect fluid hoses, electrical connections and any sensor wires connected to the current manifold assembly.
4. Remove the old manifold assembly and clean mounting surfaces and fittings to ensure a clean installation.
5. Install the new 15D560 manifold assembly in the same orientation and securely fasten all connections.
6. Reconnect fluid hoses, ensure sensor wiring is correctly attached and restore electrical power.
7. Test the sprayer under normal operating conditions for correct flow, pressure and absence of leaks.
8. Regularly inspect the manifold assembly for signs of wear, leaking connections or sensor faults, and replace as required to maintain optimal system performance.

Why Use or Replace With the 15D560?

• Using the correct OEM manifold assembly ensures proper fluid routing, sensor integration and full system compatibility.
• A worn or incorrect manifold can lead to improper flow, pressure drops, leakage or sensor malfunctions that impair sprayer output.
• Replacing the entire manifold assembly as a single unit can be more efficient and reliable than servicing multiple individual valves and ports.
