Graco 103610 Packing O-Ring

Product Details – 103610 Packing O-Ring

Compatible Machines

The Graco 103610 Packing O-Ring is used across select Graco equipment where part 103610 is specified. Always confirm by model manual or parts list before ordering.

• Graco TexSpray guns (models that specify O-ring 103610)
• Other Graco spray / pump assemblies that call out 103610 in the parts diagram

Key Specifications

Description

The Graco 103610 Packing O-Ring is a fluoroelastomer seal (014 size) used in select Graco spray and pump assemblies. Using the correct OEM O-Ring 103610 helps maintain system integrity, reduce leakage, and extend service intervals.

Fitment Guidance

• Match the part number in your machine’s IPL: look for 103610.
• If replacing an existing O-ring, compare size and cross-section with the removed part.
• For TexSpray guns, verify against the gun’s exploded view before purchase.

Installation & Care

• Clean the groove and mating surfaces before installation.
• Lightly lubricate with a seal-safe lubricant to avoid pinching/cutting.
• Do not twist the O-ring; seat evenly and reassemble to the torque in the manual.
• Replace in sets if the assembly contains multiple O-rings to maintain uniform sealing.

Quick Facts
