Graco XT Mark Vll Standard Hi-Boy Pump Breakdown (2001556) Electric Airless Sprayer Parts List

Graco XT Mark VII Standard Hi-Boy Pump Breakdown (2001556) Parts Guide

XT Mark VII is the heavyweight of Graco’s electric texture line, packing a brushless MaxPower DC motor that drives a full-stroke Endurance Chromex pump to 3300 psi while moving up to 6.4 L / min (1.7 gpm). That’s roughly 40 % more output than a Mark V, enabling crews to finish block-fill and elastomeric roof coatings in fewer passes. A Hi-Boy cart keeps the 126-lb frame nimble, and SmartControl 4.0 holds fan pattern even when voltage or viscosity drifts on site.

Graco’s 3-in-1 architecture adds job-site flexibility swap the fluid section for a mortar pump, or hook to a remote hopper for low-pressure texture without buying a second rig. The WatchDog system shuts down the pump if material runs dry, saving the rod from a heat-stroke.

The Heart of the System: Pump Breakdown 2001556

Part 2001556 is Graco’s factory-built displacement pump for every XT Mark VII Standard Hi-Boy shipped worldwide. It arrives pre-packed with V-Max Blue seals, carbide seats and a stainless steel ball set ready to bolt on with ProConnect ½-turn fasteners three minutes from box to spraying. The same pump cross-fits older Mark V XT rigs and even 695 XT models, so stocking two lowers covers most of a mixed electric fleet.

Factory Performance Specs

Top-Moving XT Mark VII Parts on Our Shelves

• 2001556 Pump Breakdown – complete wet-end, Chromex rod, pre-seated balls.
• 17H858 Seal & Seat Kit – V-Max Blue packings rated 2× longer than Teflon.
• 16U102 Prime Valve – brass body, Viton seats; replace every 750 gal.
• 244199 Inlet Seat – chrome-plated for abrasive texture and roof mastics.
• 15C811 SmartControl PCB – calibrated 0-3300 psi curve, plug-n-play.
• 246173 Wide-Bore Suction Tube – maximizes feed on bead-filled coatings.

Cross-Compatibility & Upsell Opportunities

Need a spare gun? RAC X LP 517 guard included with every XT Mark VII screws onto graco airless spray guns across the family from 695XT contractor pistols to gas-powered graco gmax 5900 and big-block GMAX II 7900 units. Swap tips, not habits, and keep overspray consistent across crews.

For small trim or cabinet runs, our 30-mesh manifold filters and graco 490 parts whip hoses bolt straight in, while the Endurance pump’s inlet rod matches both the graco 230 paint sprayer and the homeowner favorite magnum project painter plus parts. Consolidate truck stock, cut procurement time, and let one bin of graco spray tip guards serve half a dozen models.

Maintenance Blueprint—Hit 2× Pump Life

Before Each Shift – Lubricate throat with TSL, check for ½-inch belt deflection, and confirm WatchDog float action.

Every 250 hours – Replace inlet strainer, scrape piston rod, and torque pump fasteners to 55 in-lb.

Every 500 hours – Install a new seal kit, purge SmartControl memory, and pull motor brushes for wear check.

Annually – Drop in a fresh 2001556 pump, pressure-test to 3000 psi, update BlueLink hours, and archive flow data.

Pro Tips

• Color-code parts bins—blue for electronics, red for wet-end, yellow for filters to cut pick errors 50 %.
• Keep an “A-bin” of graco spray pump parts, plus one spare gun per crew; lightning surges fry guns more than pumps.
• Use the larger 60-mesh inlet filter when spraying elastomeric roof coat to prevent cavitation at 120-ft hose runs.
• Log every gallon via BlueLink; contractors report 20 % faster warranty claims with digital usage proof.

Ready to Restore Peak Performance?

From high-output graco airless spray guns to precision-ground carbide seats, SprayersAndParts carries every authentic component to keep your XT Mark VII Standard Hi-Boy earning revenue. Load your cart now and feel the uptime advantage on tomorrow’s jobsite.
