Compatible Sprayers & Product Information: Graco 244513 Fluid Filter Repair Kit
Compatible Machines
- Graco Ultra Max 695 Airless Sprayer
- Graco Ultra PC Pro Series Sprayers
- Graco Classic PC Sprayers
- Graco FinishPro II Sprayers
- Many older Graco GX Series sprayers
- Graco ST Max series sprayers
- Graco ProContractor model sprayers
What Is the Graco 244513 Fluid Filter Repair Kit?
The Graco 244513 Fluid Filter Repair Kit is a precision OEM assembly designed to restore or replace the internal fluid filter in compatible Graco airless paint sprayers. It ensures clean paint delivery by trapping debris before it enters the pump or hose, reducing tip clogs and maintaining consistent pressure.
Key Features & Benefits
- OEM replacement parts — stainless screen, gasket, and compression spring.
- Prevents debris from clogging tips and disrupting flow.
- Improves prime performance and consistent spray pressure.
- Simple drop-in installation — minimal downtime.
Technical Specifications
| Part Number | 244513 |
| Type | Fluid Filter Repair Kit |
| Includes | Filter screen, gasket, spring |
| Application | Manifold fluid filter rebuild |
Why It Matters
A worn or damaged manifold filter screen can cause paint contaminants to enter your sprayer system, leading to inconsistent spray patterns, frequent tip clogs, and lost productivity. Rebuilding the filter with the 244513 kit significantly improves performance and prolongs tip life.
Frequently Asked Questions
It replaces the internal manifold filter assembly — including the stainless filter screen, sealing gasket, and compression spring — to improve flow and prevent clogs.
Replace it whenever you experience paint flow issues, frequent tip clogs, or during regular maintenance intervals to keep your system performing smoothly.
It fits many Graco airless models with a similar manifold fluid filter design, especially older Ultra and Ultra Max stand sprayers — but always check your model’s parts diagram before purchase.
