Graco 238431 Q Strainer 60 Mesh Multi-Pack

The Graco 238431 Q Strainer 60 Mesh Multi-Pack ensures clean, clog-free spraying by trapping fine debris before it reaches your pump and tip. Designed for #7 Easy-Out manifolds, it maintains smooth performance and extends sprayer life.

  • OEM 60-mesh filter for fine material control
  • Fits Ultra Max, Ultra Plus, EH, and EM Series sprayers
  • Quick-change Q-style screen for easy cleaning
  • Sold as a 3-pack of genuine Graco strainers

$54.5
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Graco 238431 Q Strainer – 60 Mesh (Multi-Pack) | OEM Easy-Out Manifold Screen

Compatible Machines

This Graco 238431 Q Strainer 60 Mesh drops into the #7 Easy-Out manifold housing used on many pro-grade rigs. Confirm your sprayer’s manifold size (#7) before ordering.

  • Ultra Max Series: 395, 495, 595 (Hi-Boy & Lo-Boy)
  • Ultra Plus Series: Plus 1000, Plus 1500
  • Ultra Max 695 & legacy models (circa 1999–2000)
  • EH Series (Gas-Hydraulic): EH 333, EH 433
  • EM Series (Electric Stand): EM 390, EM 490, EM 590
  • Other stand/cart units that use the long 5-5/8″ Easy-Out cap and #7 manifold

Key Features

  • OEM 60-mesh filtration for fine debris control and smoother fan pattern.
  • Q-style Easy-Out screen for quick, tool-free swap-outs at the manifold.
  • Protects pump & tip by reducing clogs and abrasive wear in the fluid path.
  • Ideal with most architectural coatings; pair mesh size to material for best results.

Specifications

Part Number 238431 (Q Strainer, 60 Mesh, 3-Pack)
Mesh Rating 60 mesh (fine)
Style / Fit Q-style Easy-Out screen for #7 manifold housing
Approx. Dimensions (pkg) H 1.9″ × L 1.95″ × W 3.55″ (reference packaging)
UPC 00633955703377
Also Available 238432 – 60-mesh 25-Pack (same element, bulk qty)

Installation & Usage Tips

  1. Relieve pressure and switch to PRIME.
  2. Remove the Easy-Out cap beneath the pump block.
  3. Pull the old Q Strainer, insert a fresh 60-mesh element.
  4. Inspect/lube the O-ring, reinstall cap hand-tight, prime briefly, then SPRAY.

Frequently Asked Questions

Three (3) OEM 60-mesh Q-style manifold screen elements. For bulk packs, see 238432 (25-pack).

Check your parts manual for a #7 Easy-Out manifold and Q-style screen listing. If your unit uses a different manifold size or gun filter, 238431 will not fit.

Most interior/exterior acrylics and latex. Use 30-mesh for heavy block fillers; 100-mesh for thinner enamels to minimize tip clogs.

Manifold strainer (Q-style) for the pump block—not a gun handle filter. It installs behind the Easy-Out cap below the pump.

Pre-strain paint from the pail, flush at day’s end, and inspect edges for damage before reuse. Replace at the first sign of deformation or persistent clogs.
