Graco 100112 Fitting Elbow

The Graco 100112 Fitting Elbow provides a secure 90° air line connection for Graco elevator and pump support systems. Ideal for air control assemblies and compact routing.

  • Part Number: 100112
  • Connection: 1/4" Tube × 1/8" NPT Male
  • Used In: Air Control Kit 207561
  • Compatible: Graco Elevator Model 241663 (Series A)

$33.18
0
Based on 0 reviews
5 ★
0%
4 ★
0%
3 ★
0%
2 ★
0%
1 ★
0%

Graco 100112 Fitting, Elbow — Specs & Compatibility

Compatible Machines / Assemblies

Based on Graco parts documentation, 100112 is used in the elevator air control assembly noted below.

  • Graco Standard Elevator (Fixed Mounting) — Model 241663, Series A (includes Air Control Kit 207561 which contains 100112)
  • Elevators & Pump Supports equipped with Air Control Kit 207561 (as shown in the kit parts list)

Key Specifications

Graco Part 100112 (Fitting, 90° Male Elbow)
Tube Connection 1/4" (6.4 mm) tube push-to-connect / compression (per assembly listing)
Thread Side 1/8" NPT (male)
Typical Use Air line routing in Elevators & Pump Supports (Air Control Kit 207561)
Angle 90° elbow for compact routing

Fit Notes

  • Appears in the 207561 Air Control Kit bill of materials used on certain elevator assemblies.
  • Match both ends before ordering: 1/4" tube side and 1/8" NPT (male) thread side.
  • For other sprayers or sub-assemblies, confirm via the unit’s parts manual by searching for 100112.

Frequently Asked Questions

It’s documented in the 207561 Air Control Kit used on specific Graco Elevator assemblies (e.g., Model 241663, Series A). For other machines, check your model’s parts list for item 100112.

One side accepts 1/4" (6.4 mm) tubing; the other is a 1/8" NPT male thread. The fitting is a 90° elbow for tight spaces.

It is shown in pneumatic (air) control circuits within elevator systems. Always verify material compatibility and pressure rating against your application.

Open your model’s instruction/parts manual and review the bill of materials. If you see “100112 – Fitting, 90° male elbow; 0.25" tube, 1/8 npt” listed, it’s a match.

Yes—Graco catalogs also show a straight 1/4" tube × 1/8" NPT fitting (100113) commonly paired in the same assemblies. Verify against your manual.
