Graco 15E288 Manifold Insert
5/5
(1 review)
$16.20
Available to Order
The Graco 15E288 Manifold Insert provides precise internal fluid routing and pressure regulation inside manifold assemblies, ensuring consistent spray performance and system reliability.
- Optimizes internal fluid flow and pressure balance
- Maintains seal integrity under pressure
- OEM‑grade insert for manifold assemblies
- Ideal for industrial spray systems
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Graco 15E288 Manifold Insert
The Graco 15E288 Manifold Insert is a precision internal component designed to direct fluid flow properly within the manifold assembly — ensuring uniform pressure distribution, proper sealing, and smooth material delivery in spray‑pump systems.
Compatible Machines
- Airless and air‑assisted sprayer units using replaceable manifold insert systems
- Industrial coating rigs requiring consistent pressure and flow regulation
- High‑output spray systems for automotive, furniture, or metal finishing
- Sprayer setups maintained with OEM‑grade internal components for reliability
Specifications
| Part Number | 15E288 |
|---|---|
| Component Type | Manifold Insert |
| Material | High‑durability alloy or engineered polymer (depending on variant) |
| Function | Guides and regulates fluid flow inside manifold for consistent delivery |
| Installation | OEM replacement; requires proper seal placement and torque as per manual |
Key Features
- Ensures smooth internal fluid flow and pressure balance
- Maintains seal integrity under high-pressure conditions
- Improves reliability and longevity of manifold assemblies
- OEM‑grade fit for consistent, leak-free performance
Typical Use Cases
Used in spray systems where precise fluid flow and pressure regulation are needed — such as industrial coatings, automotive finishes, or heavy‑body material spraying, where consistency and reliability are critical.
Frequently Asked Questions
Worn inserts can cause uneven fluid flow, pressure drops, or leaks — affecting spray quality or causing system failures.
It fits manifold housings designed for 15E288 inserts — verify your system’s model and specifications before ordering.
Inspect during regular maintenance cycles — especially after heavy use or when switching coating types; replace if flow becomes uneven or pressure fluctuates.
5
1 review
1
0%
2
0%
3
0%
4
0%
5
100%
K
Kevin T.
Picked this up to replace a worn part and this 15E288 Manifold Insert and it's been reliable through several jobs since. Part #15E288 matched exactly. No issues at all - does exactly what it should.
