Graco DutyMax GH230 Standard Series Frame and Belt Guard Parts

Your One‑Stop Source for OEM Graco DutyMax GH230 Standard Series Frame and Belt Guard Parts & Kits

When performance and durability matter on the jobsite, professional contractors turn to Sprayersandparts.com your trusted destination for Graco DutyMax GH230 Standard Series Frame and Belt Guard Parts. Whether you're repairing a frame assembly, replacing a cracked belt guard, or upgrading with reinforced OEM housing, our curated selection ensures maximum uptime with contractor-grade dependability.

From rugged industrial jobs to fine-finish residential projects, your GH230 sprayer is engineered to deliver so it deserves only genuine Graco parts designed for perfect fit, performance, and longevity. That’s where we come in.

Why Choose Genuine Graco DutyMax GH230 Frame and Belt Guard Parts?

Graco’s DutyMax GH230 is a professional-grade gas hydraulic airless sprayer trusted by crews across construction, painting, stucco, and elastomeric applications. Its frame and belt guard components are key to ensuring proper structural integrity and operational safety.

Here’s why OEM Graco parts are essential:

 Built to Exact Tolerances

Graco parts are engineered specifically for the GH230 model, ensuring a precise fit every time. You’ll avoid the alignment issues and premature wear that plague off-brand imitations.

 Tested for Real-World Durability

All frame and guard parts are field-tested for impact resistance, heat tolerance, and chemical exposure critical for hydraulic systems operating in tough conditions.

 Manufacturer Warranty

Every component is backed by Graco's factory warranty, and our own technical team offers product verification and installation guidance to get you up and running fast.

What’s Included in the Graco GH230 Standard Frame and Belt Guard Parts Collection?

We carry a comprehensive lineup of replacement parts and kits for your GH230 frame and belt guard system, including:

 Frame Components

• Main frame chassis with anti-corrosion finish

• Mounting brackets and fasteners

• Shock-absorbing feet and stabilizers

• Crossbars and handle tubing assemblies

 Belt Guards & Safety Shrouds

• OEM belt guard covers with proper ventilation

• Drive belt shield assemblies

• Impact-resistant plastic and steel guard options

• Fastener kits for guard housing replacement

 Associated Hardware & Brackets

• Bolts, bushings, lock washers

• Support arms and pivot points

• Vibration dampening spacers

• Mount kits for engine and pump stabilization

All listings are updated with clear diagrams, pressure and material specs, and side-by-side images to help confirm compatibility even when referencing older equipment.

Key Features & Technical Specifications

Whether you’re referencing your Graco 7900 paint sprayer, a TrueCoat 360VSP, or aligning your GH230’s frame with other DutyMax models, specs matter. We break them down to eliminate guesswork:

Whether you're sourcing a new frame or a replacement belt shield, we help you verify fit and form before you click “add to cart.”

Pro Tips for Long-Term Reliability

Getting the right part is only the first step. Here’s how to get the most life from your Graco GH230 frame and belt guard components:

 Stick to a Service Schedule

Log frame inspections every 100 hours and belt guard integrity every 40 hours. Replace fasteners and guards showing wear or cracks before system vibrations lead to failures.

 Lubricate & Torque

Always torque frame bolts to spec and lubricate all pivot or friction joints when installing new guard components to reduce metal fatigue.

 Stock Common Wear Items

Keep extras on hand of:

• Frame bolts and lock washers

• Guard mounting screws

• Spare belt shields

• Replacement bushings

Use color-coded bins to separate GH230 parts from other series like Graco 395 or 3400.

Cross-Compatible Parts You Should Know

Many components in the Graco DutyMax GH230 are cross-compatible with other Graco models and assemblies. That includes:

• Graco 3400 Series Frame Elements

• Graco Ultra Max II 695 & 795 Belt Guards

• Graco 395 Airless Sprayer Base Frame

• Graco Magnum & TrueCoat Series Brackets

Our product listings clearly show model compatibility and superseded part numbers to help you keep your inventory lean and efficient.

Order Genuine Graco GH230 Frame and Belt Guard Parts Today

Don’t risk downtime or part mismatches. When it comes to Graco DutyMax GH230 Standard Series Frame and Belt Guard Parts, Order right!!!
