Graco GH230 is a gas-hydraulic beast tailor-made for high-solids block filler, elastomeric roof coatings, and fibered mastics. Its graco fan belt is the silent workhorse that transfers Honda GX power to the hydraulic pump. A worn, glazed, or stretched belt robs torque, overheats your fluid section, and eventually snaps—usually halfway up scaffolding. Instead of gambling on automotive look-alikes, pro contractors spec Graco OEM belts precision-milled to 5V industrial profile, complete with antistatic carbon weave and oil-resistant EPDM. We stock those belts alongside the tensioner, key-way pulley, and alignment shims so you can refresh the whole drive in one parking-lot pit stop.

Why Choose Genuine Graco GH230 Fan Belt Parts?

Engineered for 3 300 psi Duty – EPDM rubber rated -40 °F to 250 °F, with 3× burst margin for sudden tip clogs.
Antistatic Fiber Core – prevents belt dust from loading the hydraulic oil filter or fouling ignition coils.
Match-Balanced Sets – when you order two belts they’re factory paired so tension splits evenly across the pulley face.
Exact Length = Faster Swaps – no shimming or grinding guard slots; tighten to ½″ deflection and go.
Warranty Kept Intact – non-OEM belts void Graco drivetrain coverage. Stick to blue-labeled originals.

Key Features & Specs

Attribute	OEM Belt 17F332
Profile / Pitch	5V Industrial, 5/8″ top width, 0.53″ height
Effective Length	60.0 in ± 0.15 in (matched set)
Material	EPDM with Aramid/Kevlar tensile cords
Temperature Range	-40 °F – 250 °F (-40 °C – 121 °C)
Static Conductivity	R < 6 MΩ (ISO 1813 compliant)

Which Sprayers Use This Belt—and Why One Spare Saves Three Rigs

Graco engineers recycle belt profiles across gas-hydraulic families, so a single spare covers more iron than you might think:

GH230 Standard & ProContractor – factory fit, no shims.
GH300 & GH733 – identical pulley pitch; order belt plus 3 mm spacer shim.
GMAX 650 Pro – carry belt in toolbox; rescue a seized hydraulic by belt-drive swap under 30 min.
Texture behemoth Mark X IronMan – emergency field fix with one belt and an Allen key.
Electric conversions (7900 Graco paint sprayer frames) – belt transfers power from retrofit gas pack to original pump.

Fast Shipping & Pro Support

In Stock Qualified Orders placed and confirmed before by 12:00 PM and your orders leaves Graco warehouse the same day. Need belt routing art or torque spec for the graco suction hose adapter? we can connect you to Graco techs for more support.

Pro Tips for Long-Life Drive Systems

Change in Pairs – new belt + new graco whip hose equals balanced load and cleaner pressure curve.
Torque Check After First Hour – belts seat; retension to ½″ deflection, 10 lb force.
Keep a Belt Log – Sharpie install hours on the shroud. Swap at 120 h latex, 80 h block filler.
Guard Clearance = ¼″ – dust builds heat; blow out every filter change.
Use OEM Pulley Deglazer – Scotch-Brite + brake cleaner restores grip, prevents belt squeal.

Frequently Asked Questions

Will this belt fit my 10-year-old GH230?

Yes—Graco hasn’t changed pulley pitch since 2005; confirm 5V profile.

Can I install solo on a roof?

Absolutely—loosen four engine bolts, roll belt on, tension with pry bar, torque to 35 ft-lb.

Do I need to grease the belt?

No—any lubrication causes slip. Keep pulleys dry and clean.

Ready to Eliminate Belt Breakdowns?

Add the OEM 17F332 belt, a matched spare, Easy-Out filter kit and any graco accessories to your cart now. We ship—tomorrow your GH230 runs quiet, pumps smooth, and invoices stack.

Shop GH230 Fan Belt Parts →
