Graco 190 PC Hi-Boy Sprayers Parts (2)

Comprehensive OEM Graco 190 PC Hi‑Boy Sprayer Parts List

For professionals using graco magnum x5 parts and rugged jobsite equipment, the Graco 190 PC Hi‑Boy remains a top contender. To ensure optimal performance, SprayersAndParts.com offers a fully detailed graco parts list, covering everything from fluid systems to airless paint sprayer attachments, graco pump repair kit components, and the core graco airless spray gun hardware. Whether you're restoring a legacy unit or upgrading your graco spray equipment, this guide ensures you find the exact parts you need.

1. Fluid Section & Pump Components

The heart of your sprayer’s performance lies in its fluid section:

• Piston rods, seals, and O-rings – Precision components (e.g. O‑ring packing 103413; cap sealing washer 115099) ensure leak-free, high-pressure sealing in the fluid section

• Inlet strainers and manifolds – Graco 235004 inlet strainer and barbed deflector 244035 keep debris out while preserving flow consistency

• Drive housing & repair kits – The 24W817 drive housing kit and 24W640 connecting rod are essential for fluid section rebuilds, available individually or teamed with full graco pump repair kits

Using certified OEM parts ensures pressure longevity and avoids the inefficiencies of aftermarket clones.

2. Power & Control Systems

Every sprayer relies on precise motor control:

• Motor thrust bearings & thrust washers – Frequent replacement items like part numbers 107434, 116073, 116074, and 116079 maintain motor smoothness on heavy use

• Control boxes & electronics – From power cord assemblies and on/off switches to pressure transducer and potentiometer modules, SprayersAndParts.com stocks full graco airless spray gun control components.

Maintaining these systems prevents voltage irregularities, keeps speeds consistent, and preserves spray quality.

3. Frame, Hoses & Mounting Hardware

Mobility and structural integrity are key:

• Suction/drain hoses & clips – Replacement assemblies with spring clip retainers (195400) and prime hose setups ensure efficient cleaning and fluid handling.

• Frame mounts & pail hangers – Durable parts like part 17C990 and rubber grip handles offer stability on tough job conditions.


4. Spray Gun: SG3 with 517 RST Tip

Every kit includes the iconic graco airless spray gun—SG3 with 517 stainless reversible tip—for professional-grade finish consistency. Upgrades and airless paint sprayer attachments like RAC‑X guards and multi-purpose whips also integrate seamlessly into the 190 PC system.

5. Complete Graco Pump Repair Kits

Rather than piecemeal ordering, full graco pump repair kits bundle everything you need—packing kits, pistons, seats, springs—for a thorough pump rebuild. Ideal for Hi‑Boy units showing signs of pressure loss or fluid leaks. These kits often include:

• Seals and rods

• Bearing and gear packs

• Spring-loaded valves

• TSL lubrication fluid

A pump kit combined with the drive housing and rod components maintains OEM reliability.

6. Filters, Strainers & Maintenance Accessories

Consistent quality demands consistent strain protection:

• Multiple mesh filters (60–200 mesh suggested)

• Compatible OEM parts like 243080 fluid filters and 235004 strainers

• Quick-clean prime valve assemblies to prevent costly clogging

These items are essential airless paint sprayer attachments to ensure smooth, uninterrupted operation.

7. Consumables & Wearables

Frequent replacement keeps performance agile:

• O-ring packing sets (16H137)

• Garden hose inlet sealers (115099)

• Label kits and rod wipers to maintain code compliance and sprayer hygiene.

8. Ordering, Cross‑Reference & Repair Services

To simplify procurement and maintenance:

• SprayersAndParts provides exact part numbers, imagery, and compatibility checklists.

• Not sure? Use “Graco pump repair near me” to find nearby technicians and service centers for full pump overhaul or part installs.

9. Why OEM Matters for Graco

1. Pressure resilience – Genuine parts meet 3000+ PSI ratings.

2. Chemical durability – Tested against primers, elastomerics, and solvents.

3. Performance warranty – OEM components preserve factory warranty.

4. Field-tested reliability – trusted by professionals.

Silencing inefficiencies and unplanned downtime starts with using correctly engineered OEM components.

10. Smart Maintenance Plan for Hi‑Boy Systems

Pairing a graco pump repair kit with regular filter and fluid replacements keeps your system at peak capability.

Final Recommendations

• Use graco magnum x5 parts cross‑reference when sourcing fluid section components.

• Equip your sprayer with essential airless paint sprayer attachments (tip guards, whips, strainers).

• Keep a graco pump repair kit in your inventory for fast rebuilds.

• Maintain your graco airless spray gun, fluid hoses, and pressure transducer modules.

• Search “graco pump repair near me” for local expertise and service.

• Always reference the full graco parts list to ensure compatibility and OEM quality.

✅ Bottom Line

The Graco 190 PC Hi‑Boy combines rugged performance with modular ease-of-service. SprayersAndParts.com supports your operation with a complete OEM-grade parts catalog—from fluid sections to control boxes, mounts, and spray guns. Their graco spray equipment and attachments maintain peak productivity, prevent unnecessary service issues, and keep your team spraying strong. Need help? Our reps are available to guide cross‑reference, shipping priorities, and servicing advice.
