Graco 288747 Manifold Outlet Paint (Strainer Screen 40 MESH)
5/5
(1 review)
$12.10
Available to Order
The Graco 288747 Manifold Outlet Paint Strainer ensures smooth paint flow and protects your sprayer from debris buildup. Ideal for heavy coatings and consistent performance.
- Mesh Size: 40 MESH (coarse filtration)
- Fits: ProX17, ProX19, ProX21, A60/A80/ProS Series
- Design: One-way form-fitted InstaClean filter
- Purpose: Reduces clogs & extends pump life
- Easy Maintenance: Flushes automatically during cleaning
Quantity
Genuine OEM Part
Fast Shipping (Order by 1 PM CST)
Easy Returns
Compatible Machines
- Magnum ProX17 (Stand & Cart)
- Magnum ProX19 (Stand & Cart)
- Magnum ProX21 (Stand & Cart)
- Magnum A60 ProPlus
- Magnum A80 ProPlus
- Magnum ProS19 ProPlus
- Magnum ProS21 ProPlus
Part Overview
The Graco 288747 Manifold Outlet Paint Strainer is a 40 MESH (InstaClean) filter that traps debris before it reaches your tip, helping prevent clogs, ensuring a smoother finish, and protecting the pump. Its form-fitted one-way design installs in the correct orientation for dependable flow.
Quick Specs
| Part Number | 288747 |
|---|---|
| Type | Manifold outlet strainer / InstaClean filter |
| Mesh Rating | 40 MESH (coarser filtration for heavier paints) |
| Primary Function | Reduces tip clogs, improves finish quality, protects pump & valves |
| Install Direction | One-way, form-fitted—cannot be inserted backwards |
Benefits
- Fewer clogs at the tip and smoother spray pattern
- Protects pump by catching debris before the outlet
- Consistent flow for better, more even finishes
- Easy maintenance—InstaClean design flushes during cleanup
When to Choose 40 MESH
Use 40 MESH for medium-to-heavy coatings such as interior/exterior latex and primers. For very fine materials, a finer mesh may be recommended (check your sprayer manual and material data sheet).
Installation & Care
- Depressurize the sprayer per the manual.
- Access the manifold outlet and remove the old filter.
- Insert the 288747 with the correct orientation (one-way design).
- Reassemble, pressurize with water/solvent, and check for proper flow.
- Rinse/flush after use to extend filter life.
Frequently Asked Questions
Yes—it's compatible with ProX17, ProX19, and ProX21 (Stand & Cart). It also fits A60 ProPlus, A80 ProPlus, ProS19 ProPlus, and ProS21 ProPlus. Some ProX7/ProX9 and XR units use the same interface; verify your manual to confirm.
40 MESH is coarser and ideal for heavier paints (latex/primer). Finer meshes capture smaller particles but may reduce flow with thicker coatings. Always match mesh to material and tip size recommendations.
Replace when you notice frequent tip clogs, pressure spikes/drops, or visible damage. With regular flushing and clean materials, many pros replace every few projects or when performance changes.
Yes. The form-fitted one-way design ensures proper orientation. Inserting backwards can restrict flow or cause malfunction.
For ultra-fine finishes, you may need a finer mesh and appropriate tip size. Check the coating’s technical data sheet and your sprayer’s manual for recommendations.
