Graco Ultra Max II:1095 Hi-Boy Pump Breakdown

Complete Selection of Factory-Approved Graco Ultra Max II 1095 Hi-Boy Pump Breakdown in Stock

When Graco Ultra Max II 1095 Hi-Boy pump uptime decides whether you finish a condo tower tonight or face liquidated-damage penalties tomorrow, pros click “Add to Cart” at SprayersAndParts.com for all graco sprayers part. Our site still carry every serialized screw, seat, seal, and SmartControl™ board for this large-electric legend—heat-bagged, torque-tagged, and backed by bench-pressure tests so you spray, not pray, on site.

Why Choose Genuine Graco Ultra Max II 1095 Pump Parts?

• Chromex® Rod + MaxLife™ Seats—64 Rc hardened surfaces shrug off TiO₂ plus silica that carves knock-off rods in a weekend.
• V-Max Blue™ Hybrid Packings—self-lubricating UHMW/leather stack holds 300 psi stain or 3 300 psi block filler with zero weep.
• SmartControl 3.0 Firmware—OEM sensor locks fan width at ±1 %; clone boards “hunt” and blow 10 % more paint into overspray.
• ProConnect™ 2 Door—swap a blown lower in 60 s; save the 30-minute bench vise dance.
• Warranty Stays Intact—Graco honours its Endurance™ one-year/SmartControl cover only with serialized parts.

Key Features & Specs

Spare Once, Save Many—Rigs Sharing 1095 DNA

Graco engineered one stroke length and clutch geometry across its large-electric family. Your single 1095 kit rescues:

• Ultra Max II 1095 & 1595—identical rods, seats, packings.
• Mark IV/V Texture Sprayers—same Endurance lower; board jumper sets motor amperage.
• GMAX 7900 Gas Rigs—lower, Easy-Out™ filters, Contractor PC gun cartridge swap straight in.
• LineLazer V 3900 Stripers—filter core and seat kit match for overnight road-stripe fixes.
• 395/490 PC Pro—Easy-Out filters, RAC X tips and parts for Graco 395 paint sprayer cross-fit, making one field bin serve two crews.

Top-Moving Ultra Max II 1095 Pump Parts

1. 17C487 Endurance™ Pump Lower—Chromex rod, V-Max packings, MaxLife seats; pressure-tested to 5 000 psi.
2. 17Y297 Contractor PC Gun—five-minute cartridge rebuild; see exploded view in the graco paint sprayer parts diagram.
3. 240 797 BlueMax II 100-ft Hose—⅜″ ID dual-swivel; maintains 2 900 psi at 0.031″ tip across parking lots.
4. 17G180 RAC X LP 517 Tip + Guard—sprays wall latex at 1 400 psi; OSHA meter shows 3 dB quieter rigs.
5. Easy-Out™ 30-/60-/100-mesh Filter Pack—yellow (roof coat), black (latex), blue (enamel) swap in seconds.
6. Pump Armor™ Gallon—locks out rust; mandatory per Graco warranty.

Five Field-Proven Habits for a 1 000-Hour 1095

• Warm Flush 100 °F—latex dissolves 30 % faster; BlueMax liner safe 160 °F.
• Wet-cup TSL—five drops each break; dry cups score Chromex rods.
• Rotate Hose Ends Weekly—balances liner wear, keeps SmartControl capacitance tight.
• Mesh-to-Tip Rule—30-mesh ≥ 0.025″ tips; 60-mesh for 0.017–0.023″; 100-mesh for graco fine finish sprayer.
• Colour-code bins—blue electric, red gas, green handheld; avoid wrong-kit grabs.

Frequently Asked Questions

Will Endurance pump 17C487 drop into a 1095 built in 2004?

Yes—stroke length unchanged; reuse existing ProConnect door.

Maximum hose length with 0.031″ tip?

200 ft total: ⅜″ BlueMax first 150 ft, ¼″ whip last 50 ft; maintain 2 900 psi.

Can I spray solvent enamel?

Packings solvent-rated; flush mineral spirits and store in Pump Armor™.

Ready to Turn Downtime into Billable Gallons?

Add an Endurance pump, Easy-Out filter kit and RAC X LP tip bundle to your cart now. We’ll ship —tomorrow your Ultra Max II 1095 fires first trigger, sprays flat, and invoices flow.

Shop 1095 Pump Parts →
